AC Gearmotor, 60 rpm, Open, 115V
$207.74 /ea
This item ships free. Details.Standard ground shipping.
Details:
Shaft Length (Dimension V): 1.5"_x000D_Gear Ratio: 27:1Nameplate RPM: 60AC Gearmotor, Gearmotor Voltage 115VAC, 1 Gearmotor Phase, Max. Torque 59.0 in.-lb., Single Gearmotor Shaft Type, Gearmotor Shaft Orientation Parallel, Gearmotor Rotation CW, Nameplate RPM 60, Open Gearmotor Enclosure, All Angle Gearmotor Mounting Position, 60 Hz, Overhung Load 150 lb., Input HP 1/10, Gear Ratio 27:1, Full Load Amps 2.6, Insulation Class B, None Thermal Protection, Motor Type Shaded Pole, Unpainted Finish, Die Cast Zinc Housing
Specifications
| Zoro #: G1850572 Mfr #: 1LPL6 | |
| Shaft Length (Dimension V): 1.5"_x000D_ | Gear Ratio: 27:1 |
| Nameplate RPM: 60 | Max. Ambient Temp.: 40 Degrees C |
| Thermal Protection: None | Housing: Die Cast Zinc |
| Insulation Class: b | RPM Range: 51 to 75 |
| Shaft Dia. (Dimension U): 5/8" | Reversible Shaft Output: No |
| Hz: 60 | Enclosure: Open |
| Length Less Shaft: 7-7/8" | Standards: RU/CSA |
| Motor Type: Shaded pole | Phase: 1 |
| Voltage: 115 | Gear Case Material: Die Cast Zinc |
| Input HP: 1/10 | Max. Torque: 59.0 in.-lb. |
| Overhung Load: 150 lb. | Mounting: All Position |
| Rotation: CW | Gear Material: Acetyl/Steel |
| Full Load Amps: 2.6 | Shaft Orientation: Parallel |
| Item: AC Gearmotor | Finish: Unpainted |
| Bearings: Porous Bronze Sleeve on Case, Ball on Motor | Lubrication: Grease filled |
| Gears: Acetyl/Steel | Shaft: Single Output |
| Keyway Size: #605 Woodruff Key | Seals: Lip Type on Output Shaft |
| Country of Origin (subject to change): United States | |
Description
AC Gearmotor, Gearmotor Voltage 115VAC, 1 Gearmotor Phase, Max. Torque 59.0 in.-lb., Single Gearmotor Shaft Type, Gearmotor Shaft Orientation Parallel, Gearmotor Rotation CW, Nameplate RPM 60, Open Gearmotor Enclosure, All Angle Gearmotor Mounting Position, 60 Hz, Overhung Load 150 lb., Input HP 1/10, Gear Ratio 27:1, Full Load Amps 2.6, Insulation Class B, None Thermal Protection, Motor Type Shaded Pole, Unpainted Finish, Die Cast Zinc Housing
