Gas Pressure Regulator with Solenoid Valve, 1/2" DN15, 24V DC, IP65

The HONEYWELL KROMSCHRODER VAD115R/NW-100B is a pressure regulator intended for regulation and control of gas pressure in industrial systems. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane within specified parameters. It features an outlet with DN 15 (1/2'') Rp internal thread and operates within an outlet pressure range of 35–100 mbar.

Key features include:

• Maximum inlet pressure: 500 mbar (7 psig)
• Features rapid actuation mechanism
• Mains voltage: 24 V DC; electrical connection via M20 cable gland
• Integrated pilot lamp for status indication
• Protection rating: IP65
• FM and SA approved; EU certified
• No inlet flange; size 1 configuration
• Valve seat reduced design; right-side accessory port for a pressure switch (30–110 mbar)
• Left-side accessories include two screw plugs
