Solenoid Gas Safety Valve - 500 mbar, IP65, Flow Adjustment, VAS2T50

The HONEYWELL KROMSCHRODER VAS2T50/-N/LQSL is a Class A solenoid gas safety valve intended for use as an automatic shut-off valve in gas and air systems. The valve remains closed when de-energized and is rated for a maximum operating pressure of 500 mbar. It is equipped with an integrated pilot lamp, flow adjustment capability, and IP65-rated enclosure. This model is certified to applicable EU standards, approved by FM and CSA, and certified according to SIL 3 and PL e requirements.

Key features include:

• Size range: 1 to 9; nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening with quick closing or slow opening with quick closing
• Compatible with mains voltages of 24 V DC, 120 V AC, or 230 V AC
• Electrical connection provided via terminal block
• Available versions include models equipped with visual position indicators, bypass/pilot gas valves, or integrated pressure switches
