Solenoid Gas Safety Valve, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS125R/NW is a Class A solenoid gas safety valve intended for use as a shut-off valve in gas and air systems. It conforms to EN 161 standards, is normally closed when not energized, and is rated for a maximum operating pressure of 500 mbar. The unit includes pilot lamp and adjustable flow settings, with an IP65 rating for ingress protection. This model has obtained EU, FM, CSA certifications; suitable for installation in systems requiring up to SIL 3 or PL e compliance (verify actual scope if needed).

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage compatibility: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and fitted pressure switches
