Solenoid Gas Safety Valve - VAS Series, Class A, 500 mbar, IP65 Rated

The HONEYWELL KROMSCHRODER VAS240R/NW is a Class A solenoid gas safety valve intended for use in applications requiring automatic shut-off of gas and air. It compliant with EN 161 standards, configured to remain closed when de-energized, and is rated for operation at pressures up to 500 mbar. The unit features a pilot lamp and flow adjustment, an IP65-rated enclosure, and is certified under applicable EU, FM, and CSA requirements. It meets the requirements for application in systems classified up to SIL 3 and PL e.

Key features include:

• Size range: 1 to 9
• Nominal diameter (DN): 10 to 125
• Connection options: threaded or flanged
• Opening/closing types: quick opening/quick closing or slow opening/quick closing
• Mains voltage options: 24 V DC, 120 V AC, or 230 V AC
• Electrical connection via terminal block
• Available versions include models with position indicator, visual indicator, fitted bypass or pilot gas valve, and pressure switches DG../VC
