Hydraulic Filter, replaces SCHROEDER NZ3V, 3 micron, Outside-In

Main Filter Hydraulic Filter,  replaces SCHROEDER NZ3V,  3 micron,  Outside-In MF0604657
Tap to zoom
Hover or click to zoom
  • Replaces OEM Brand: SCHROEDER
  • Filter Rating (Microns): 3
  • Flow Direction: Outside-In
See full product details
Orders over $75 ship free.

Total: $33.82

Main Filter #MF0604657 Specifications

  • Replaces OEM Brand: SCHROEDER
  • Replaces OEM Part: NZ3V
  • Filter Rating (Microns): 3
  • Flow Direction: Outside-In
  • Beta Ratio 1: 200/3
  • Beta Ration 2: 1000/4.5
  • Seal Type: Viton
  • Height: 5.24
  • OD Top: 1.77
  • OD Bottom: 1.77
  • ID Top: 0.77
  • Collapse Pressure: 217
  • Micron Rating: 3
  • OEM Replacement Brand: SCHROEDER
  • Item: Hydraulic Filter
  • Application: Filtration
  • Weight: 0.416
  • Product Media: Glass
  • Country of Origin (subject to change): Canada


Main Filter MF0604657 replaces OEM NZ3V by SCHROEDER and is compatible in fit, form and function.Filter Technical Specifications Product Media: Glass Micron Rating: 3 Seal Type: Viton Height: 5.24in OD Top: 1.77in OD Bottom: 1.77in ID Top: 0.77inAll of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.Images may be a general representations of products

Restrictions and Compliance

  • This item has been restricted from sale in the following states: No
