IKL68 AL SERVENTR SPLICE A:4/0 B:3/0 5.5, 100PK

Aluminum 4 inch Service Entrance Compression Splice for Wire Range - Black End: 3/0 ASCR, 3/0 STR, 4/0 CPT, 3/0 CPR. Pink End: 4/0 ASCR, 4/0 STR, 250 CPT, 4/0 CPR. Installing Dies: TX 249 840 (EEI 11A). Compound and Capped. includes 5-7/16 inch Sleeve. General Characteristics. Category : Wire or cable compression splice. Special Features : Pre-insulated for fast, easy installation of large home or commercial service entrances. Concave polyethylene end caps seal out dirt, but are easily pierced when inserting conductor. Application : For Combinations of Aluminum-to-Aluminum and Aluminum to-Copper Conductors. Use as a low tension reducing sleeve for Insulated Conductor. Connection : Compression. Conductor Range : End A: 4/0 ACSR , 4/0 STR , 4/0 COMPR , 250 kmcil COMPT. End B: 3/0 ACSR , 3/0 STR , 3/0 COMPR , 4/0 COMPT. Number Of Conductors : 2. Material : Aluminum. Insulation : yes. Mounting : None. Environmental Conditions : All Seasons / Conditions. Dimensions and Classifications. Brand Name : Blackburn. Standard : RUS Listed. Passes the Requirements of ANSI C119.4. Size : Splice 4 inch, Sleeve 5-1/2 inch
