Rotary Gear Pump Head, 3/4 In., 3/4 HP

DAYTON| Zoro #: G1356862| Mfr #: 4KHF5

$598.43 /ea

This item ships free. DetailsStandard ground shipping

Technical Specifications

Zoro #: G1356862 Mfr #: 4KHF5
Max. Viscosity: 550 SSUHP @ 40 PSI: -
GPM @ 80 PSI: -HP @ 80 PSI: -
Recommended Motor HP: -HP @ 60 PSI: -
GPM @ 40 PSI: -HP @ 20 PSI: -
GPM @ 20 PSI: -Max. Pressure: 125 psi
Pump RPM: 1725GPM @ 60 PSI: -
Item: Rotary Gear Pump HeadDesign: Pedestal
HP @ Free Flow: 3/4HP @ 100 PSI: 1-1/2
GPM @ 125 PSI @ 1725 RPM: 9.7Seal: Mechanical With Stainless Steel, Buna N, Carbon/Ceramic
Pump Body Material: BronzeGPM @ Freeflow: 10.8
GPM @ 25 PSI: 10.7GPM @ 50 PSI: 10.6
HP @ 50 PSI: 1GPM @ 75 PSI: 10.5
GPM @ 100 PSI: 10.2GPM @ 125 PSI: 9.7
Temp. Range: -20 Degrees to 210 Degrees FGear: Fortron PPS Spur
Relief Valve: WithShaft Material: 304 Stainless Steel
Shaft Height: 2-5/8"Port Size: 3/4"
Suction Lift @ 1725 RPM: 12.3 ft.O-Ring Material: Buna N
HP @ 25 PSI: 3/4Suction Lift: 12.3 ft.
HP @ 125 PSI: 1-1/2Duty Rating: Heavy
Shaft Dia.: 0.63"HP @ 75 PSI: 1
Width: 10-3/8"HP @ 125 PSI @ 1725 RPM: 1-1/2
HP @ Free Flow @ 1725 RPM: 3/4Length: 3-3/4"
GPM @ Freeflow @ 1725 RPM: 10.8Height: 3-1/4"
Country of Origin (subject to change): India

Product Description

Rotary Gear Pump Head, Duty Rating Heavy, Pedestal, Pump Body Material Bronze, Port Size 3/4 In., Recommended Motor HP -, Pump RPM 1725, Temp. Range -20 Degrees to 210 Degrees F, Max. Pressure 125 psi, Max. Viscosity 550 SSU, Gear Fortron PPS Spur, Length 3-3/4 In., Width 10-3/8 In., Height 3-1/4 In., O-Ring Material Buna N, Relief Valve With, Seal Mechanical With Stainless Steel, Buna N, Carbon/Ceramic, Shaft Dia. 0.63 In., Shaft Height 2-5/8 In., Shaft Material 304 Stainless Steel
