This item is Discontinued.

Gigabyte Gigabyte Z590 AORUS ULTRA Socket LGA1200 Intel Z590 DDR4 SATA3 & USB3.2 M.2 Wi-Fi & Bluetooth Mini-ITX Motherboard Z590 AORUS ULTRA

This item is Discontinued.

Gigabyte

Gigabyte Z590 AORUS ULTRA Socket LGA1200 Intel Z590 DDR4 SATA3 & USB3.2 M.2 Wi-Fi & Bluetooth Mini-ITX Motherboard (Discontinued)

Mfr # Z590 AORUS ULTRA
Zoro # G903775149
UPC # 889523026496
Country of Origin China
Category Motherboards
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
Z590 AORUS ULTRA
Zoro #
G903775149
UPC #
889523026496
Country of Origin
China

Description

Features
  • 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
  • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 Memory Modules (operate in non-ECC mode)
  • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 Memory Modules
  • Support for Extreme Memory Profile (XMP) Memory Modules
  • Dual channel memory architecture
CPU:
  • 11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors
  • 10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors
  • L3 Cache varies with CPU
Audio:
  • Realtek ALC1220-VB codec
  • Support for DTS:X Ultra
  • High Definition Audio
  • 2/4/5.1/7.1-Channel
Storage Interface:
  • CPU: 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A-CPU)
  • Chipset: 1 x M.2 connector on the back of the motherboard (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support) (M2P-SB)
  • Support for RAID 0, RAID 1, RAID 5 and RAID 10
  • Intel Optane Memory Ready
  • 4 x SATA 6Gb/s Connectors
Internal I/O Connector:
  • 1 x 24-pin ATX main power connector
  • 1 x 8-pin ATX 12V power connector
  • 1 x CPU fan header
  • 3 x system fan headers
  • 1 x addressable LED strip header
  • 1 x RGB LED strip header
  • 4 x SATA 6Gb/s connectors
  • 2 x M.2 Socket 3 connectors
  • 1 x front panel header
  • 1 x front panel audio header
Back Panel Connectors:
  • 1 x DisplayPort
  • 1 x HDMI port
  • 1 x USB Type-C port, with USB 3.2 Gen 2x2 support
  • 3 x USB 3.2 Gen 2 Type-A ports (red)
  • 2 x USB 3.2 Gen 1 ports
  • 2 x USB 2.0/1.1 ports
  • 1 x Q-Flash Plus button
  • 1 x RJ-45 port
  • 2 x SMA antenna connectors (2T2R)
  • 3 x audio jacks
Specifications
  • Chipset: Intel Z590 Express Chipset
  • Memory 11th Generation Intel Core i9/i7&

Restrictions
