  11. Plate Caster, Swivel, Heavy-Duty, 3000 lb.
Hamilton Plate Caster, Swivel, Heavy-Duty, 3000 lb. S-SECJ-1025VH - main

Plate Caster, Swivel, Heavy-Duty, 3000 lb.

  • Mfr # S-SECJ-1025VH

  • Zoro # G7426170

product price: $205.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Swivel
Wheel/Tread Material
Steel
Caster Brake Type
No Brake
Wheel Dia.
10 in
Wheel Width
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
S-SECJ-1025VH
Zoro #
G7426170
UPC #
-
Country of Origin
Multiple

Dimensions

Wheel Dia.
10 in
Wheel Width
2 1/2 in
Mounting Height
12 1/2 in
Mounting Plate Size
5-1/4 in x 7-1/4 in
Mounting Plate Thickness
3/8 in
Mounting Bolt Dia.
1/2 in
Overall Height
12-1/2in
Swivel Radius
7 1/8 in
Recommended Track Size
1-1/2 in x 1-1/2 in
Inside Slot Spacing - Width
3.375 in
Overall Wheel Width
2 1/2 in
Outside Slot Spacing - Width
4.125 in
Mounting Plate Width
5 1/4 in
For Axle Dia.
3/4 in
Inside Slot Spacing - Length
5.25 in
Mounting Plate Length
7 1/4 in
Outside Slot Spacing - Length
6.125 in

Details

Item
Plate Caster
Caster Sub-Type
Swivel
Wheel/Tread Material
Steel
Caster Brake Type
No Brake
Load Rating
3000 lb
Wheel Bearing Type
Roller
Wheel Hardness Rating
170 BHN
Number of Mounting Holes
4
Tread Shape
V-Groove
Caster Frame Material
Steel
Core Color
Red
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Inside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Caster Plate Hole Pattern
A
Replacement Wheel
Mfr. No. WW-1025-V-1MC
Features
Corrosion Resistant
Application
Commercial, General Purpose, Industrial, Institutional
Standards
ANSI ICWM
Wheel Color
Red
Caster Brake Included
No
Frame Finish
Zinc Plated
Extended Lead
No
Caster Temp. Range Available
No
Thread Guards
No
Includes
Spanner
Swivel Construction
Kingpinless
Wheel/Tread Hardness Rating
Extra Hard
Clearance on 1-1/2" Track
9/16 in
Swivel Raceway Type
Single Ball
Load Rating Range
3000 to 5999 lb
Wheel Core Material
Iron
Includes Thread Guards
No
Swivel Lock Type
No Lock Included
Wheel Type
Flat-Free
Caster Features
Corrosion-Resistant
Load Capacity - Maximum
3,000 lb
Compatible With
WW-1025-V-1MC
Wheel Core Type
Solid
Mounting Plate Shape
Rectangle
Mounting Hole Type
Slot
For Surface Type
Concrete
Operating Temperature - Maximum
320 Degrees F
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature Range
-40 Degrees to 320 Degrees F

Description

Swivel, Plate Caster, Load Rating 3000 lb, Swivel Lock Type No Lock Included, Wheel Dia. 10 in, Wheel Width 2 1/2 in, Wheel/Tread Material Steel, Wheel Core Material Iron, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape V-Groove
