Gas Pressure Regulator & Solenoid Valve, 24V DC, DN15, IP65, VAG1-/25R/NWSLAE

The HONEYWELL KROMSCHRODER VAG1-/25R/NWSLAE is a gas valve rated for use in controlling gas pressure within specified system parameters. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), making it compatible with gas, air, and biologically produced methane as per manufacturer specifications. The device features rapid actuation mechanism, operates at a maximum inlet pressure of 500 mbar (7 psig), and provides an outlet pressure range from 35 to 100 mbar.

Key features include:

• Integrated pilot lamp for status indication
• IP65 rated enclosure
• FM and SA approvals; EU certified
• Outlet connection: DN 15 (1/2") Rp internal thread; no inlet flange
• Mains voltage: 24 V DC with M20 cable gland electrical connection on the right side of the connection box
• Valve seat: reduced type; size 1 configuration
• Right-side accessory port supports a pressure switch (30–110 mbar) with test point at outlet pressure; left side includes two screw plugs
