Gas Pressure Regulator & Solenoid Valve, 500 mbar, DN15, IP65 Rated
Mfr # KS88006678
Zoro # G915398664
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAG 2 /40R/NWAN is a gas valve intended for use in controlling gas pressure in industrial and commercial systems. This unit includes both a Class A pressure regulator compliant with EN 88 standards and a Class A solenoid valve conforming to EN 161 standards, compatible with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and is rated for outlet pressures between 35–100 mbar. The device features quick open/close operation, is equipped with a pilot lamp for status indication, and offers electrical connection via an M20 cable gland.
Key features include:
- Includes Class A pressure regulator compliant with EN 88 standards
- Solenoid valve compliant with EN 161 standards
- Maximum inlet pressure: 500 mbar (7 psig)
- Outlet: DN 15 (1/2") Rp internal thread; no inlet flange
- Includes quick open/close operation
- Equipped with pilot lamp; enclosure rated IP65
- Certified by FM, SA, and EU authorities
- Electrical connection supports mains voltage at 24 V DC through M20 cable gland on right side of the connection box
- Valve seat is reduced; right-side accessory port accommodates a compatible pressure switch (30–110 mbar)
- Right-hand test point provided for measuring outlet pressure; left side fitted with two screw plugs
Restrictions
