Gas Pressure Regulator & Solenoid Valve, DN15, 24V DC, VAG120R/NWAE
Mfr # KS88002579
Zoro # G115398587
Specifications
Product Information
Description
The HONEYWELL KROMSCHRODER VAG120R/NWAE is a gas valve intended for use in applications requiring regulation of gas pressure. This unit integrates both a Class A pressure regulator (EN 88) and a Class A solenoid valve (EN 161), suitable for use with gas, air, and biologically produced methane. It operates at a maximum inlet pressure of 500 mbar (7 psig) and includes quick open/close mechanism as specified by manufacturer. The device includes an integrated pilot lamp for status indication, has an IP65 rating for ingress protection, and holds FM and SA approvals as well as EU certification.
Key features:
- Outlet: DN 15 (1/2") Rp internal thread
- Mains voltage: 24 V DC; electrical connection via M20 cable gland
- Outlet pressure range: 35–100 mbar
- Valve seat: reduced type
- Accessories include right-side pressure switch (30–110 mbar) with test point on outlet side; left side fitted with two screw plugs
- No inlet flange included
- Size designation: Size 1
