  6. Switches and Lighting Controls, Industrial Grade, Toggle Switches, General Purpose AC, Three Way, 15A 347V AC, Terminal Screws, Black Nylon Key Guide

This item is Discontinued.

Hubbell Wiring Device-Kellems Switches and Lighting Controls, Industrial Grade, Toggle Switches, General Purpose AC, Three Way, 15A 347V AC, Terminal Screws, Black Nylon Key Guide HBL18203LCN

Switches and Lighting Controls, Industrial Grade, Toggle Switches, General Purpose AC, Three Way, 15A 347V AC, Terminal Screws, Black Nylon Key Guide (Discontinued)

  • Mfr # HBL18203LCN
  • Zoro # G400702020
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
HBL18203LCN
Zoro #
G400702020
UPC #
783585924748
Country of Origin
United States

Dimensions

Length
4.06 in
Width
1.3 in
Height
1.86 in
Display Size
Standard Product Size
Dimensions
4.06 in x 1.3 in x 1.86 in
Wire Size
#14 AWG to #10 AWG

Details

Switch Type
Three Way
Color
Black
Voltage
347V AC
Type
Locking
Style
Three Way
Temp. Rise
30°C maximum at rated current
Temp. Rating
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Brand
Hubbell Wiring Device-Kellems
Actuator
Double Ended Key
Action
Snap
Contact Configuration
3-Position
Contact Rating
Full Rated
Application
General Purpose
Number Of Poles
Single Pole
Carton Quantity
10
Connectivity
Back and Side Wired
Lock Type
Non-Cylindrical
Load Capacity
Inductive or Resistive
Amperage
15 A
Voltage Rating
347 VAC
Dielectric Strength
Withstands 1500V AC minimum for 1 minute
Current Rating
15 A
Series
Extra Heavy Duty
Switch Grade
Industrial
Operating Temperatures
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Switch Handle Positions
2
Temperature Rise
30°C maximum at rated current
Operating Temperature
Max. continuous: 75°C; Min. continuous: -40°C without impact
Max. Continuous Current
15A
Toggle Color
Locking
Terminal Accommodations
#14 AWG min. - #10 AWG max. solid and stranded copper wire only
Product Type
Toggle-switches
Dielectric Voltage
Withstands 1500V AC minimum for 1 minute
Flammability
UL 94V-2
Overload
Minimum 4.8 times rated current for 100 cycles
Wiring Style
Back and Side Wired
Max. Working Voltage
277V AC
Listing and Certifications
CSA Certified
Amperage Rating
15 A
Indicator(s) Type
Dot Indicates On
Current / Amperage Rating
15 A
Temperature Rise - Max.
30°C maximum at rated current
Voltage Rating Description
347 VAC
Temperature Rating
Max Continuous- 75 Degrees C, Minimum- -40 Without Impact
Performance
Electrical - Dielectric Voltage - Withstands 1500V AC minimum for 1 minute Electrical - Max. Continuous Current - 15A Electrical - Max. Working Voltage - 277V AC Electrical - Overload - Minimum 4.8 times rated current for 100 cycles Electrical - Temperature Rise - 30°C maximum at rated current Environmental - Flammability - UL 94V-2 Environmental - Operating Temperature - Max. continuous: 75°C, Min. continuous: -40°C without impact Mechanical - Terminal Accommodations - #14 AWG min. - #10 AWG max. solid and stranded copper wire only
OEM Brand Name
Hubbell Wiring Device-Kellems
Industry Standard(s)
UL Listed
Wattage
6940 W
Material - Mounting Hardware
Mounting Screws

Description

Hubbell Wiring Device Kellems, Switches and Lighting Controls,Industrial Grade, Toggle Switches, General Purpose AC, Three Way, 15A347V AC, Terminal Screws, Black Nylon Key Guide
