Product Information
MFR #
IC107F6VWH
Zoro #
G409850999
UPC #
633758092692
Country of Origin
Taiwan, Province of China
Details
Color
White, Transparent Red
Temperature
-40° to 150° F (-40° to 68° C)
Jack Style
HD
Current rating
1.5 amps
Housing
ABS, UL 94V-0
Plug Retention Force
30 lbs min
Contact Resistance
20 mohms max
Plug and Jack Contact Force
100 grams min
Plug Insertion Life
750 cycles min
Product Type
Keystone Jacks
Insulation Resistance
500 mohms min
Performance
CAT6
DC Resistance
0.1-ohm max
Jack Wiring
50 Micro Inches of Gold over 100 Micro Inches of Nickel
Termination Cap
PC, UL 94V-0
Connector
Insulation Displacement Connection (IDC), 8P8C
Description
- CAT 6 rated connectors provide excellent performance for data networks requiring maximum speed and bandwidth.- PCS technology provides maximum performance and superior signal quality.- Enhanced crosstalk cancellation reduces return loss and improves performanceby rejecting noise and unwanted signals.- Exceeds ANSI/TIA-568-C requirements for permanent, channel link and componentPerformances.- Engineered to provide 110 IDC termination reducing installation time- Reduced rear footprint allows for greater connectivity density and provides for more port configurations in a smaller area.- Includes an integrated TIA-568A/B color wiring diagram- Backwards compatible to all lower rated category components- Compatible with all IC107 faceplates, inserts, surface mount boxes, and blank patch panels.- Compatible with all IC108 furniture faceplates, bezels, and surface mount boxes.- Used with ICC Category 6 ICPCSK series patch cords, 110 punch down tool ICACSPDT00, and JackEasy 4-Pair termination tool ICACSPDTEH.
