PATCH BOX, MOBILE, CAT 6, 6-PORT (Discontinued)
Mfr #
ICMPPMB606
Zoro #
G709851115
UPC # 633758028493
Country of Origin Taiwan, Province of China
Category Voice & Data Patch Panels
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- ICMPPMB606
- Zoro #
- G709851115
- UPC #
- 633758028493
- Country of Origin
- Taiwan, Province of China
Details
- Dust Cover
- Soft PVC, UL 94V-0
- 110 Connector
- Copper alloy, 100 microinches of bright solder over 100-micron inches of nickel underplate
- Temperature Range
- -40 degrees C to 150 degrees F
- Force
- 100 grams
- Current Rating
- 1.5 amps max
- Strain Relief
- Soft PVC, UL 94V-0
- Dielectric Withstanding Voltage
- 1000 volts RMS, 60 Hz
- Plug Retention in Jack
- 30 lbs (133N) min
- Ports
- 6
- Gold Rating
- 50 micro inches of gold over 100 micro inches of nickel
- Jack Housing
- ABS, UL 94V-0
- Wire leads
- 26 AWG solid wire
- Connector
- 8P8C
- Color xx
- BK-Black
- Cover and Base
- Polypropylene, UL 94V-0
- Spring Wire
- Square spring wire, tempered phosphorous bronze
- Contact Resistance
- 5 milliohms
- Product Type
- Mobile Boxes
Description
Provides a 6-port outlet appropriate for open architectural environments- Suitable for use with either 4 or 25-pair cable- Rugged construction allows for long lasting use- Optional mounting on steel surfaces with magnets ICMAGBLOCK- Enhanced crosstalk cancellation reduces return loss & noise- Exceeds ANSI/TIA/EIA-568-B.2 Cat 6 connecting hardware requirements- Used with ICPCS6 Cat 6 patch cords & ICACSPDT00 110 punch down tool- UL Listed: UL 94V-0 fire retardant
