This item is Discontinued.

Icc PATCH PANEL, CAT 6A, 48-PORT, 2 RMS ICMPP0486B

This item is Discontinued.

Icc

PATCH PANEL, CAT 6A, 48-PORT, 2 RMS (Discontinued)

Mfr # ICMPP0486B
Zoro # G209851141
UPC # 633758092234
Country of Origin Taiwan, Province of China
Category Voice & Data Patch Panels
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ICMPP0486B
Zoro #
G209851141
UPC #
633758092234
Country of Origin
Taiwan, Province of China

Dimensions

Size
3.47 height x 19.00 width x 1.28 depth

Details

Marking
Mold UL information
Mounting
Rack
IDC
Phosphor Bronze Alloy with 100 micro-inch 100% Sn alloy
Electrical Insulation Resistance
500 mohms min @ 100v DC
Spring Wire
Phosphor Bronze alloy plated with 50 micro-inch of gold over 70~100 micro-inch of nickel
IDC Contact Resistance
2.5 mohms max.
Ports
48
Housing
Zinc alloy fully shielded
Retention
50n (11 lbs sq) or 60s±5s
Rack Space
2
Insertion/Extractor
750 cycles min.
Dielectric Withstanding Voltage
1000v DC or AC peak
Connector
8P8C
IDC Wire Guage
22~24 AWG
Temperature Range Storage
-40° to 70°c
Product Type
110 Panels
Spring Wire Contact Resistance
20 mohms max.

Description

CAT6A 48-Port 110-Type Patch Panel- Vertical 110-Type IDC connections reduces potential Alien Crosstalk ANXT- Enhanced crosstalk cancellation and reduced return loss for high bandwidth network requirements- Exceeds ANSI/TIA-568 CAT 6A 10G connecting hardware Component Rating requirements- 110-Type IDC termination helps reduce installation time and improve wire retention- 50 micro inch gold plating on all modular contacts to protect from corrosion- 2 rack mount spaces RMS, Mounts on industry standard 19In. wide racks or equipment- T568A or T568B wiring schemes; not compatible with 110-type patch plug- UL Listed
