Specifications
Product Information
MFR #
L34104
Zoro #
G703509050
UPC #
-
Country of Origin
Czechia
Dimensions
Thread Size
1/2 in
Cable Outside Diameter
8 mm
Details
Number of Contacts
3 Pin
Mounting Style
Male Thread
Item
1/2 in Circular Connector
Application
AC Power
Maximum Operating Temperature
194 Degrees F
Connector Body Type
Pin
Housing Material
Nylon
IP Rating
IP67
Minimum Operating Temperature
-13 Degrees F
Includes Nut
Yes
Locking Style
Screw Connection
Number of Poles
3
Connector Orientation
Straight
Voltage Rating
250V AC
Coding
C
Connection Type
Cable Connection With Screw Terminals
Description
1/2 in Circular Connector, Mounting Style Male Thread, Application AC Power, Number of Poles 3, Coding C, Connection Type Cable Connection With Screw Terminals, Thread Size 1/2 in, Voltage Rating 250V AC, Nominal Voltage 250V AC, Locking Style Screw Connection, Housing Material Nylon, Includes Nut Yes, Connector Body Type Pin, Cable Outside Diameter 8 mm, Connector Orientation Straight, Maximum Operating Temperature 194 Degrees F, Minimum Operating Temperature -13 Degrees F, IP Rating IP67
