Electric Actuator, 70 to 115 sec.

Johnson Controls Electric Actuator, 70 to 115 sec. M9116-AGD-2
Tap to zoom
Hover or click to zoom
Feedback Help us improve our product images
$235.63
  • Mounting Type: Direct Mount
  • Spring Return: No
  • Signal Type: Floating, On/Off
See full product details
This item ships free.
Total: $235.63

Johnson Controls #M9116-AGD-2 Specifications

  • Mounting Type: Direct Mount
  • Spring Return: No
  • Signal Type: Floating, On/Off
  • Torque: 140 in-lb
  • Voltage: 24V AC/DC
  • Height: 6 in
  • Item: Electric Actuator
  • Motor Direction: CW or CCW
  • For Use With: Dampers and Valves
  • Shaft Type: Self-Centering Clamping
  • Ambient Temp. Range: -4 Degrees to 122 Degrees F
  • Power Consumption: 5.8VA
  • Timing: 70 to 115 sec
  • Depth: 2 11/16 in
  • Width: 4 1/4 in
  • Includes: Anti Rotation Bracket
  • Stroke Deg.: 90
  • Electrical Connections: Screw Terminals
  • Country of Origin (subject to change): Mexico
Feedback Help us improve our product information

Description

Electric Actuator, Non-Spring Return, Shaft Type Self-Centering Clamping, Torque (In.-Lbs.) 140, Stroke Deg. 90, Height (In.) 6, Width (In.) 4-1/4, Depth (In.) 2-11/16, Screw Terminals, Floating, 122, 5.8 VA, Timing (Sec.) 70 to 115, Voltage 24 AC/DC, 5.8, Dampers and Valves, Includes Anti Rotation Bracket
