Johnson Controls

Pressure Control, 0 to 150

product price: $136.47
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Switch Type SPST
  • Switch Action Open on Fall
  • Pressure Connection 1/4 in Male Flare
  • Type High Pressure
  • Range (PSI) 0 to 150
See all product information

Product Information

Dimensions

Mounting Hole Diameter 1/4 in, 3/8 in
Overall Depth 2 1/8 in
Pressure Connection Size 1/4 in
Overall Width 4 in
Overall Height 4 1/4 in

Details

Item Single Pressure Control
Switch Type SPST
Switch Action Open on Fall
Pressure Connection 1/4 in Male Flare
Type High Pressure
Range (PSI) 0 to 150
Close (PSI) 100
Reset Auto
Differential Pressure (PSI) 10 to 70
Open (PSI) 80 psi
Application Fan Cycling
Enclosure NEMA 1
Includes Mounting Bracket
Function High Pressure Applications
Pressure Range Adjustability Adjustable
Reset Type Automatic Reset
Product Type Single Pressure Control
Pressure Differential Max. 70 psi
Element Type Bellows
Weight 2.4 lb
Pressure Setting High
Minimum Operating Temperature 50 Degrees F
Standards UL Listed
NEMA Rating NEMA 1
Pressure Range - Maximum 150 psi
Pressure Type Differential
Body Material Steel
Series P170
Pressure Connection Type Flare
Input Sensor Type Pressure Sensor
Pressure Differential - Minimum 10 psi
Contact Form SPST
Rated Voltage 120V AC, 208/240V AC
Mounting Orientation Flat, Horizontal, Vertical
Pressure Connection Gender Male
Electrical Connection Type Hardwired
Pressure Range - Minimum 0 psi

Description

Single Pressure Control, Product Type Single Pressure Control, Pressure Range - Maximum 150 psi, Pressure Differential - Minimum 10 psi, Pressure Range - Minimum 0 psi, Pressure Differential Max. 70 psi, Pressure Range Adjustability Adjustable, Pressure Connection Gender Male, Pressure Connection Type Flare, Time Delay Setting Not Applicable, Pressure Setting High, Pressure Connection Size 1/4 in, Rated Voltage 120V AC, 208/240V AC, Contact Form SPST, Switch Action Open on Fall
