Angular Bearing, 3201/5201, 12 mm Bore
Mfr # 5201 ZZ/C3 PRX
Zoro # G0350695
product price:Â
$
14.19
/ea
Key Features
Bore Dia.
12 mm
Outside Dia.
32 mm
Width
15.9 mm
Cage Material
Nylon
Type
Double Row
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 5201 ZZ/C3 PRX
- Zoro #
- G0350695
- UPC #
- 888569102256
- Country of Origin
- China
Dimensions
- Bore Dia.
- 12 mm
- Outside Dia.
- 32 mm
- Width
- 15.9 mm
- Outside Diameter
- 32 mm
- Overall Width
- 15.9 mm
- Outside Diameter Tolerance
- +/-0.01 mm
- Bore Diameter
- 12 mm
- Bore Diameter Tolerance
- +/-0.008 mm
Description
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 3201/5201, Bore Diameter 12 mm, Cage Material Nylon, Closure Double Shielded, Contact Bearing Type Angular Contact, Lubricant Material Chevron SRI 2 Grease, Mobil Polyrex EM, Matched Bearing Type Not Matched/Single Bearing, Maximum Speed 17,000 RPM, Maximum Temperature 347 Degrees F, Minimum Temperature -40 Degrees F, Number of Rows Two, Outside Diameter 32 mm, Overall Width 15.9 mm, Ring Material Alloy Steel
