Shop BODINE

13215 W, 1400 lm Linear Fluorescent Emergency Ballast

  • Mfr # B50

  • Zoro # G4292233

product price:  $167.99
/ea
Free Shipping & Returns

Key Features

Item - Emergency Lighting and Exit Signs
Fluorescent Emergency Ballast
Lamp Watts - Emergency Lighting and Exit Signs
13 to 215
Lamp Type - Fluorescent Lighting Battery Backup Systems
4-Pin CFL, Biax, T5, T5HO, T8, T9, T10, T12
Initial Lumens - Emergency Lighting and Exit Signs
Up to 1600
Housing Material
Galvanized Steel
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
B50
Zoro #
G4292233
UPC #
663015109047
Country of Origin
Mexico

Dimensions

Length - Emergency Lighting and Exit Signs
13-5/16"
Width
2 1/4 in
Height
1 1/4 in
Lamp Length Supported
2 ft to 8 ft
Length
13 3/8 in
Bulb Length Supported - Minimum
8 ft
Bulb Length Supported - Maximum
2 ft

Details

Item - Emergency Lighting and Exit Signs
Fluorescent Emergency Ballast
Lamp Watts - Emergency Lighting and Exit Signs
13 to 215
Lamp Type - Fluorescent Lighting Battery Backup Systems
4-Pin CFL, Biax, T5, T5HO, T8, T9, T10, T12
Initial Lumens - Emergency Lighting and Exit Signs
Up to 1600
Housing Material
Galvanized Steel
Voltage - Emergency Lighting and Exit Signs
120/277
Number of Lamps Supported
1 or 2
Emergency Illumination Time - Emergency Lighting and Exit Signs
90 min.
Lamp Watts
13-215
Lamp Type
T5, T5HO, T8, T12, 4-pin CFL, Biax, Philips LED T8 Instafit Lamps
Item
Emergency Fluorescent Ballast
Initial Lumens
500 to 1600 lm
Emergency Illumination Time
90 min
Input Voltage
120 to 277V AC
Battery Type
Nickel Cadmium
Standards
cULus Listed
Includes
Parts Kit with Labels
Number of Bulbs Supported
1, 2
Ballast Bulb Type
T10, T12, T5, T5HO, T8, T9
Frequency
50/60 Hz
Meets Class 2 Electrical Wiring
No
Profile
Low Profile
Brand and Series
Bodine
Wiring Connection
Wiring Attached
Operating Amps @ 120V
0.06 A
Recharge Time
24 hr
CA Title 20 Compliant
No
Temperature Range
32 Degrees to 122 Degrees F
For Use With
Fluorescent Emergency Lighting
Bulb Watts
215W
Ballast Type
Electronic
Max. Bulb Watts
215 W
Operating Temperature - Minimum
32 Degrees F
Initial Light Output - Maximum
1,600 lm
Initial Light Output - Minimum
500 lm
Compatible Product Type
122 Degrees F

Description

Bodine, Electronic, Emergency Fluorescent Ballast, Input Voltage 120 to 277V AC, Number of Bulbs Supported 1, 2, Max. Bulb Watts 215 W, T10, T12, T5, T5HO, T8, T9 Ballast Bulb Type, Initial Lumens 500 to 1600 lm, Galvanized Steel Housing Material, 13 3/8 in Length, 2 1/4 in Width, 1 1/4 in Height, Low Profile, 90 min Emergency Illumination Time, 24 hr Recharge Time

Restrictions

Hazardous material
This item has been restricted from sale in the following states: CA
