Shop BURNDY

Connector, Bronze, Overall L 2.25in

  • Mfr # C11HD4/0DB

  • Zoro # G4657511

product price:
$
26.99
/ea

Key Features

Item - Grounding Connector
Grounding Connector
Type - Grounding Connector
Mechanical
Type
Commercial
Wire Size - Grounding
8 to 4/0 AWG
Material
Bronze
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
C11HD4/0DB
Zoro #
G4657511
UPC #
781810347751
Country of Origin
India

Dimensions

Wire Size - Grounding
8 to 4/0 AWG
Conductor Size
4/0 AWG to 8 AWG
Rod Dia.
1/2" to 1" Pipe, 3/8" to 1" Rod, #4 to #8 Rebar
Grounding Wire Size
8 to 4/0 AWG STR
For Maximum Pipe Size
1 in
For Maximum Ground Conductor Wire Size
4/0 AWG
For Minimum Ground Conductor Wire Size
8 AWG
For Rod Dia.
3/8 in to 1 in
Overall Length
2 21/32 in
For Minimum Pipe Size
1/2 in
Overall Width
1 9/16 in
Overall Height
2 1/4 in
Conductor - Copper Str Size Range
8 AWG-4/0 AWG
Conductor - Pipe EMT Size Range
36893
Dimension - Width fraction
1-14/25 in
Dimension - Width mm
40 mm
Conductor - Rod Size
3/8 in;1/2 in;5/8 in;3/4 in;7/8 in;1 in
Conductor - Rebar Size Range
45022
Dimension - Width inch
1.56 in
Conductor - Pipe EMT Size
1/2 in;3/4 in;1 in
Dimension - L Length Overall mm
67 mm
Dimension - Height inch
2.25 in
Conductor - Rebar Size
4 ;5 ;6
Dimension - Length Overall inch
2.65 in
Dimension - Height fraction
2.888888888888889 in
Conductor - Copper Str Size
8 AWG;7 AWG;6 AWG;5 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 ;2/0 AWG;3/0 AWG;4/0 AWG
Conductor - Rod Size Range
3/8 in-1 in
Wire Rope Length
2 21/32 in
Length
2 21/32 in

Details

Item - Grounding Connector
Grounding Connector
Item
Grounding Connector
Type - Grounding Connector
Mechanical
Type
Commercial
Material
Bronze
Grounding Wires Connected To
#4 to #6 Rebar, 1/2 in to 1 in Pipe, 3/8 in to 1 in Rod
Standards
UL Listed Direct Burial, UL467
Material - Grounding Connector
Cast Bronze
Number of Wires - Grounding
1
Material of Construction
Solid Cast Bronze
For Use With
Copper Conductor, Ground Rod, Rebar, Water Pipe
Description/Special Features
Direct Burial, EMT or Rigid Conduit
Torque
50 in-lb
Accessory Type
Ground Clamp
Application
For Connecting Grounding Conductor, EMT Or Rigid Conduit To Water Pipe, Copper Tube, Ground Rod Or Rebar, Direct Burial Applications
Industry Standard(s)
UL467
Plating Type
Zinc
Certification - UL Listed Direct Burial
Yes
Material - Hardware
Zinc Plated Steel
Certification - CSA Approved
Yes
UL Listed
Yes
Plated
N
Standards - Industry Standards Met
UL467
Installation Torque Recommended in-lb
50 LBS/in

Description

Grounding Connector, Grounding Wire Size 8 to 4/0 AWG STR, Material Bronze, Number of Wires - Grounding 1, Description/Special Features Direct Burial, EMT or Rigid Conduit, For Maximum Ground Conductor Wire Size 4/0 AWG, For Minimum Ground Conductor Wire Size 8 AWG, For Use With Copper Conductor, Ground Rod, Rebar, Water Pipe, Grounding Wires Connected To #4 to #6 Rebar, 1/2 in to 1 in Pipe, 3/8 in to 1 in Rod, Standards UL Listed Direct Burial, UL467, Type - Grounding Connector Mechanical
