Shop TRITAN

Insert Ball Brng, ER, 1-7/16 dia, 5777.59lb

  • Mfr # ER23

  • Zoro # G9563845

product price:
$
30.89
/ea

Key Features

Bore Dia.
1.4375"
Width
42.9mm
Width (In.)
15/16 in
Dynamic Load Capacity (Lb.)
5770
Locking Type
Setscrew
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
ER23
Zoro #
G9563845
UPC #
888569014788
Country of Origin
China
Item
Insert Bearing
Dynamic Load Capacity (Lb.)
5770
Locking Type
Setscrew
Bearing Material
52100 Steel
Series
ER Series
Includes
Retaining Ring, Set Screws
Dynamic Radial Load Capacity
5,770 lbf
Minimum Temperature
-40 Degrees F
For Environment
Chemical, Food and Beverage
Seal Type
Contact
Rolling Element Material Grade
AISI 52100
Features
Compact in Design, Lubrication Groove on Opposite Side, Snap Ring on Set Screw Side, Standard Duty, Wide Inner Ring
Maximum Temperature
248 Degrees F
Shaft Locking Type
Set Screws
Load Direction
Radial
Standards
AFBMA, ISO Certified 9001
Seal Material
Rubber
System of Measurement
Inch
Application
Commercial, Industrial
Static Radial Load Capacity
3,440 lbf
Bearing Industry Number
ER-23
Lubrication Openings
Groove with Oil Hole
Bearing Insert Shape
Cylindrical
Rolling Element Rows
1
Ball Material
Chrome Steel
Closure
Double Sealed
Ring Material Grade
AISI 52100
Ring Material
Chrome Steel
Bearing Insert Type
Radial/Deep Groove Ball
Ball Material Grade
AISI 52100
Rolling Element Material
Chrome Steel
Number of Rows
1
Bearing Lubrication
Relubricateable
Industry Number
ER23
Lubricant Material
NLGI #2 Equivalent
Internal Clearance
C3

Description

Insert Bearing, Ball Material Alloy Steel, Bearing Industry Number ER-23, Bearing Insert Type Radial/Deep Groove Ball, Bearing Insert Shape Cylindrical, Bore Diameter 1 7/16 in, Closure Double Sealed, For Environment Chemical, Food and Beverage, Maximum Temperature 250 Degrees F, Minimum Temperature -40 Degrees F, Outer Ring Width 0.937 in, Outside Diameter 2 53/64 in, Ring Material Alloy Steel, Rolling Element Material Alloy Steel, Rolling Element Rows 1, Seal Type Contact
