Shop FASCO

Rectangular OEM Specialty Blower, 2880 RPM, 1 Phase, Direct Drive, Steel 1 Speed

  • Mfr # 70213484X

  • Zoro # G8518632

product price:  $119.99
/ea
Free Shipping & Returns

Key Features

CFM @ 0.100-In. SP
70
Drive Type
Direct Drive
Full Load Amps
0.62/0.6 A
Housing Material
Steel
Inlet Dia.
2 5/8 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
70213484X
Zoro #
G8518632
UPC #
-
Country of Origin
Mexico

Dimensions

Inlet Dia.
2 5/8 in
Overall Height
5 11/16 in
Overall Width
5 7/16 in
Blower Wheel Diameter
3 in
Overall Depth
5 1/2 in
Outlet Width
2 5/8 in
Outlet Height
2 1/16 in
Blower Wheel Width
1 13/16 in
Lead Length
7 in
Inlet Diameter
2 5/8 in
Wheel Diameter
3 in
Wheel Width
1 3/4 in

Details

CFM @ 0.100-In. SP
70
Drive Type
Direct Drive
Full Load Amps
0.62/0.6 A
Housing Material
Steel
Number of Speeds
1
Phase
1
Blower Item
OEM Specialty Blower
Blower Outlet Shape
Rectangular
With Flange
Yes
Blower Motor Type
Shaded Pole
Blower Voltage
115V AC
Blower Thermal Protection
Auto
Blower Conduit Box
No
CFM @ 0.500-In. SP
24
Bearing Type
Sleeve
Not For Use With
Not Intended For Use As Inline Blowers For Wood Burners
CFM @ 0.400-In. SP
49
RPM
2880
Item
OEM Specialty Blower
Mounting Position
All Position
CFM @ 0.000-In. SP
76
Housing Color
Gray
Wheel Type
Forward-Curved
Max. Ambient Temp.
104 Degrees F
Max. Inlet Temp.
104 Degrees F
CFM @ 0.300-In. SP
57
Housing Finish
Paint
Agency Compliance
UL/CSA
Motor Enclosure
Totally Enclosed
Hz
50/60
CFM @ 0.200-In. SP
63
CFM @ 0.150-In. SP
65 cfm
Motor Insulation
Class B
Electrical Connection
Wire Leads
Motor Speed
2,880 RPM
Includes Drive Package
Yes
Maximum Ambient Temperature
104 Degrees F
Motor Insulation Class
B
Wheel Material
Steel
Discharge Position
All
Airflow @ 0.100 in SP
70 cfm
Maximum Inlet Air Temperature
104 Degrees F
Nameplate Voltage
115V AC
Mounting Orientation
Multiposition
Maximum Fan Speed
2,880 RPM
Motor Type
Shaded Pole
Rotation
CW
Flange Type
Flanged
Assembly
Assembled
Mount Type
All Position
For Air Type
Clean Air
Airflow @ 0.400 in SP
49 cfm
Airflow @ 0.000 in SP
76 cfm
Airflow @ 0.500 in SP
24 cfm
Outlet Shape
Rectangular
Housing Material Finish
Painted
Thermal Overload Protection
Yes
Includes Motor
Yes
Frequency
50/60 Hz
Minimum Ambient Temperature
40 Degrees C
Current
0.62/0.6 A
Number of Inlets
1
Number of Discharge Positions
4
Motor Horsepower
1/100 hp
Standards
CSA Certified, UL Listed
OEM Replacement
No
Voltage
115

Description

OEM Specialty Blower, Wheel Type Forward-Curved, Drive Type Direct Drive, Includes Drive Package Yes, Assembly Assembled, Wheel Diameter 3 in, Airflow @ 0.000 in SP 76 cfm, Airflow @ 0.100 in SP 70 cfm, Airflow @ 0.400 in SP 49 cfm, Airflow @ 0.500 in SP 24 cfm
