Eye Bolt With Shoulder, M10-1.50, 35 mm Shank, 27 mm ID, Steel, Plain
- Mfr # M10
- Zoro # G2385126
CAD Available
product price:Â
$
13.19
/ea
Key Features
CAD Drawing
Shoulder Style
With Shoulder
System of Measurement
Metric
Thread Size
M10-1.50
Shank Length
35 mm
Eye Inside Diameter
27 mm
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- M10
- Zoro #
- G2385126
- UPC #
- -
- Country of Origin
- United States
- CAD Available
- Yes
- Item
- Machinery Eye Bolt
- Shoulder Style
- With Shoulder
- System of Measurement
- Metric
- Material
- Steel
- Finish
- Plain
- Working Load Limit
- 740 kg
- Application
- Lifting
- Eyebolt Type
- Lift with Shoulder
- Type
- Machinery Eye Bolt
- Includes Nut
- Nut Not Included
- Pack Size
- Small Pack
- Thread Type
- Coarse
- Eye Closure
- Closed
- Globally Sourced
- Made in USA*
- Manufacturer Location
- Made in USA*
- Drive Type
- No Drive
- Material Quality Standards
- ASTM A489
- Thread Style
- Fully Threaded
- Working Load Limit - Force
- 740 kgf
- Material Grade/Class
- C1030/C1035
- Shell Material
- Steel
- Traction Material
- Steel
Dimensions
- Thread Size
- M10-1.50
- Shank Length
- 35 mm
- Eye Inside Diameter
- 27 mm
- Overall Length
- 96 mm
- Thread Length
- 35 mm
- Screw Size
- M10
- Shoulder Length
- 5.59 mm
- Eye Outside Diameter
- 46 mm
- Shoulder Diameter
- 19.81 mm
- Shank Diameter
- 10 mm
- Dia./Thread Size
- M10-1.50
- Eye Outside Dia.
- 46.0 mm
- Shoulder Dia.
- 19.05 to 20.57mm
- Eye Inside Dia.
- 27 mm
- Shank Dia.
- 10 mm
- Wire Rope Length
- 96 mm
- Length
- 96 mm
Description
Machinery Eye Bolt, System of Measurement Metric, Eyebolt Type Lift with Shoulder, Material Steel, Finish Plain, Thread Size M10x1.50, Thread Length 35 mm, Shank Dia. 10 mm, Shank Length 35 mm, Shoulder Dia. 19.05 to 20.57mm, Shoulder Length 5.59 mm, Eye Inside Dia. 27 mm, Eye Outside Dia. 46.0 mm, Overall Length 96 mm, Length from Ream Center -, Working Load Limit 740 kg, Includes -
