Shop HUBBELL WIRING DEVICE-KELLEMS

Cord Connector, 1-1/2 in., Straight, White

  • Mfr # SHC1063

  • Zoro # G6601612

product price:
$
78.29
/ea

Key Features

Material
Aluminum
Box Connection
1 1/2 in MNPT
Cord Dia. Range
1.63 in to 1.75 in
Liquid Tight / Dust Tight
Liquid Tight
Connector Type
Straight
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SHC1063
Zoro #
G6601612
UPC #
783585200637
Country of Origin
United States

Dimensions

Cord Dia. Range
1.63 in to 1.75 in
Length - Box to End of Connector
2 3/16 in
Length
2 15/16 in
Min. Throat Dia.
1.50"
Length - External Strain Relief
No External Strain Relief
Hub Trade Size
1-1/2"
Hub Size
1 1/2 in
Form Size
F6
Overall Length
2 15/16 in
Thread Size
1 1/2 in
Compatible Conduit Trade Size
1 1/2 in
Dimension E A/C
2.97" (75.4)
Dimension E A/F
2.75" (69.8)
Dimension D
1.50" (38.1) Throat Dia.
Dimension C
.75" (19.0)
Dimension B
2.20" (55.9) Ref.
Dimension A
3.00" (76.2) Dia.
Recommended Knockout Hole Size
1.97"- 2.02" (50.0-51.2)
Cord Diameter Range
1.63"- 1.75" (41.3- 44.4)
Display Size
1 1/2" NPT
Wire Rope Length
2 15/16 in

Details

Item
Liquid Tight Cord Connector
Material
Aluminum
Box Connection
1 1/2 in MNPT
Liquid Tight / Dust Tight
Liquid Tight
Connector Type
Straight
Number of Cords
1
Hazardous Location Rating
Class I, Division 2, Class II, Division 1 & 2, Class III, Division 1 & 2
Male/Female
Male
Strain Relief Type
No External Strain Relief
Material - Cord Connector
Aluminum
Material - External Strain Relief
No External Strain Relief
Color
White
Item - Cord Connector
Liquid Tight Cord Connector
Gland Color Code
No Code
Insulated
No
Style - Connector
Straight
Standards
CSA Certified, Title 46-Part 111, UL 514B, United States Coast Guard Approval
Body Color - Cord Connector
Silver
For Use With
Kellems Wire Management
Body Color
Silver
Collar Material
Aluminum
Minimum Operating Temperature
-30 Degrees F
For Minimum Cable OD
1.63 in
Thread Gender
Male
Liquid Tight
Yes
Body Material
Aluminum
Maximum Operating Temperature
240 Degrees F
Connection Orientation
Straight
NEMA Rating
NEMA 12, NEMA 13, NEMA 4, NEMA 4X
Compatible Conduit Type
Liquid Tight Cord Connector
For Maximum Cable OD
1.75 in
Bushing Material
Neoprene
Thread Type
NPT
Grommet Color Code
No Code
IP Rating
IP66
Environmental Rating
Hazardous Locations
Product Type
Cord Connectors
Color Code
White
Certifications
UL Listed in accordance with Standard 514B, CSA Certified, United States Coast Guard Approval, Title 46-Part 111.
Flammability
Hubbell nylon cord connectors have a UL 94-V2 rating.
Material/Style
Aluminum
Cord Connector Body Style
Straight Male
Hazardous Locations
Hubbell cord connectors are suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C. Reference 501-4(b), 502-4(a), 502-4(b), 503-3(a), and 503-3(b).
Effective Operating Temperature
-30°F to +240°F (-34°C to +115°C)
Temperature Rating
Minimum -30 Deg F to 240 Deg F (-34 Deg C to 115 Deg C)
Item Type
Cord Connectors
Type
Straight Male
Material - Mounting Hardware
Locknut or Tapped Opening
Performance
Environmental - Hazardous Locations - Used in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class Ill Div. 1 & 2 in accordance with the NEC Environmental - Operating Temperatures - -30°F to +240°F (-34°C to +115°C)
Environmental Conditions
Suitable For Use In Wet Locations When Used With A Listed Nylon Washer Between Box And Fitting.
Series
Standard Duty
Application
Straight Male- Form 6
OEM Brand Name
Hubbell Wiring Device-Kellems
Number Of Conductors
Single
Industry Standard(s)
UL Listed
Conductor Range
1.63-1.75 in (41.3- 44.4 mm)

Description

Liquid Tight Cord Connector, Cord Dia. Range 1.63 in to 1.75 in, Box Connection 1 1/2 in MNPT, Material - Cord Connector Aluminum, External Strain Relief Material No External Strain Relief, Gland Color Code No Code, Body Color - Cord Connector Silver, Number of Cords 1, Style - Connector Straight, Strain Relief Type No External Strain Relief, External Strain Relief Length No External Strain Relief, Length - Box to End of Connector 2 3/16 in, Insulated No
