Shop NSI TORK

Compact Fluorescent, HID, Inductive, LED Photocontrol, 4,620 W, Gray, 3 sec Max, 2 sec Min

  • Mfr # 2002

  • Zoro # G2501362

product price:  $16.59
/ea

Key Features

Compatible Lighting
Compact Fluorescent, HID, Inductive, LED
AC Operating Voltage
208-277V AC
Ballast Current - Maximum
0.416666667
Incandescent Current - Maximum
16.7 A
Wattage - Maximum
4,620 W
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
2002
Zoro #
G2501362
UPC #
786261600165
Country of Origin
China

Dimensions

Depth
1 5/8 in
Width
1 5/8
Length
4 1/2 in
Manufacturers Warranty Length
5 yr
Overall Height
4.5 in
Stem Thread Size
1/2''
Overall Depth
1.63 in
Stem Diameter
1/2 in
Overall Width
1.63 in

Details

Item
Photocontrol
Compatible Lighting
Compact Fluorescent, HID, Inductive, LED
AC Operating Voltage
208-277V AC
Ballast Current - Maximum
0.416666667
Incandescent Current - Maximum
16.7 A
Wattage - Maximum
4,620 W
Foot Candles On
1.0 to 5.0
Time Delay - Maximum
3 sec
Foot Candles Off
3 to 15
Time Delay - Minimum
2 sec
Housing Material
Polycarbonate
Temp. Range
-40 Degrees to 140 Degrees F
Body Color
Gray
Setting
Dusk to Dawn
Contact Form
SPST
For Use With
Decorative Lighting, Flood and Patio Lamp
Enclosure Type
Raintight
Standards
cULus
Description/Special Features
Built-In Delay of Up to 2 min Prevents False Switching, LED Rated
Includes
Gasket, Lock Nut
Series
2000
Indoor/Outdoor Usage
Outdoor
On Illumination - Minimum
1 fc
Resistance Properties
Moisture Resistant, Weather Resistant
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature - Maximum
140 Degrees F
On Illumination - Maximum
5 fc
Off Illumination - Maximum
15 fc
Off Illumination - Minimum
3 fc
Mounting Style
Stem
Features
Translucent Dome

Description

Photocontrol, Mounting 1/2 in Conduit, 180 Degrees Swivel, Voltage 208 to 277V AC, Max. Wattage 4,620, Max. Incandescent Amps 16.7 A, Max. Ballast Amps 10 A, 1.0 to 5.0 Foot Candles On, 3 to 15 Foot Candles Off, Color Gray, Temp. Range -40 Degrees to 140 Degrees F, Length 4 1/2 in, Width 1 5/8, Depth 1 5/8 in, Enclosure Type Raintight, Contact Form SPST, Housing Material Polycarbonate, Setting Dusk to Dawn, Standards cULus, Includes Gasket, Lock Nut
