Lifting Magnet, 2200 lb Flat Cap, 11 1/4"L
Mfr # CL2200
Zoro # G6984993
product price:Â
$
1,524.99
/ea
Free Shipping & Returns
Key Features
Max. Heat Resistant Temp.
300 Degrees F
Required Material Thickness for Max Rated Capacity
3 in
Magnet Width
9 3/4 in
Magnet Activation
Non-Marring Roller Cam
Overall Height
7 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- CL2200
- Zoro #
- G6984993
- UPC #
- 682241220401
- Country of Origin
- United States
- Max. Heat Resistant Temp.
- 300 Degrees F
- Magnet Activation
- Non-Marring Roller Cam
- Standards
- ASME B30.20
- Features
- Jack Screw Secondary Release, Stainless Steel Casing, Minimal Torque Required to Release Load, Lift Capacity Stated On Magnet, Spring Return Handle
- Max. Rated Flat Capacity
- 2,200 lb
- Item
- Lifting Magnet
- Footnotes
- Max. Rated Capacities Based On Clean, Polished Steel and Dependant on Material Thickness and Size
- Magnet Material
- Ceramic
- Includes
- Non Marring Roller Cam
- Minimum Operating Temperature
- -148 Degrees F
- Maximum Flat Load Capacity
- 2,200 lb
- Number of Poles
- 12
- Maximum Load Capacity
- 2,200 lb
- Maximum Operating Temperature
- 300 Degrees F
- Activation Mechanism
- Pry-Off Handle with Nonmarring Roller
Description
Lifting Magnet, Maximum Flat Load Capacity 2,200 lb, Maximum Round Load Capacity Not Applicable, Minimum Thickness for Activation 3/16 in, Minimum Thickness for Maximum Load Capacity 3 in, Activation Mechanism Pry-Off Handle with Nonmarring Roller, Magnet Length 11 1/4 in, Magnet Width 9 3/4 in, Magnet Height 2 1/2 in, Overall Length 15 in, Overall Width 10 1/2 in, Overall Height 7 in, Bail Inside Width 3 in, Bail Inside Length 2 7/8 in, Handle Length 16 in
