  6. One-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple
Panduit One-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple LCBX4/0-12-X - main

One-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple

  • Mfr # LCBX4/0-12-X

  • Zoro # G0774851

product price:  $17.19
/ea

Key Features

For Wire Size
4/0 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCBX4/0-12-X
Zoro #
G0774851
UPC #
7498343730
Country of Origin
Mexico

Dimensions

For Wire Size
4/0 AWG
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
1.19 in
Cable Size
4/0 AWG
Length
3.85"
Width
1.19"
Overall Length
3.85 in
Tongue Thickness (mm)
4.1
Overall Length (mm)
97.8
Tongue Thickness (In.)
0.16
Stud Hole Size (In.)
1 to 2
Class K Copper Flex Conductor Size (AWG)
36617
Barrel Length (In.)
2.24
DLO Copper Flex Conductor Size (AWG)
36617
Wire Strip Length (In.)
2.3125
Class H Copper Flex Conductor Size (AWG)
36617
Class I Copper Flex Conductor Size (AWG)
36617
Copper Code Conductor Size (AWG)
36617
Stud Hole Size (mm)
12.7
Overall Length (In.)
3.85
Class G Copper Flex Conductor Size (AWG)
36617
Barrel Length (mm)
56.9
Class M Copper Flex Conductor Size (AWG)
36617
Tongue Width (mm)
30.2
Tongue Width (In.)
1.19
Wire Strip Length (mm)
59

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
15
Color Code
Purple
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Connector Type
Long Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Angled Connector, Corrosion Resistant
T & B Die Index Number
15
Product Type
Copper Compression Connectors - Lugs
Finish/Coating
Tin-Plating
Base Material
Copper
UL Temperature Rating (°C)
90
Maximum Voltage (kV)
35
Panduit Die Index Number
P54
Tongue Type
Standard
Burndy Die Index Number
15
Connector Plating
Tin
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Wire Termination

Description

Lug Compression Connector,4/0 AWG

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
