  11. One-Hole Compression Lug, 250 kcmil Max, Standard Barrel, Copper, Yellow
Panduit One-Hole Compression Lug, 250 kcmil Max, Standard Barrel, Copper, Yellow LCAX250-38F-X - main

One-Hole Compression Lug, 250 kcmil Max, Standard Barrel, Copper, Yellow

  • Mfr # LCAX250-38F-X

  • Zoro # G0773908

product price: $22.19
/ea

Key Features

Cable Size
250 kcmil
Connector Type
Standard Barrel
Width
1.28"
Material
Copper
Length
2.13"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX250-38F-X
Zoro #
G0773908
UPC #
7498343572
Country of Origin
Mexico

Dimensions

Cable Size
250 kcmil
Width
1.28"
Length
2.13"
Overall Length
2.13 in
Tongue Width (mm)
32.5
Stud Hole Size (mm)
9.5
Copper Code Conductor Size (kcmil)
250
Overall Length (mm)
54.1
Stud Hole Size (In.)
44993
Wire Strip Length (mm)
27
Tongue Thickness (mm)
4.3
Tongue Thickness (In.)
0.17
Barrel Length (In.)
1.03
Barrel Length (mm)
26.2
Tongue Width (In.)
1.28
Overall Length (In.)
2.13
Barrel Size
Standard
Tongue Width
1.28 in
For Wire Size
250 kcmil

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Yellow
Item
One-Hole Compression Lug
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant, 90° Angled Connector
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
Tongue Angle
90 Degrees Angled
Burndy Die Index Number
16
Finish/Coating
Tin-Plated
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Base Material
Copper
Panduit Die Index Number
P62
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,250 Kcmil
