This item is Discontinued.
This item is Discontinued.
Socket, Power Relay, 10 A, 2, Quick Connect, Solder (Discontinued)
Mfr #
KUEP-7D15-24
Zoro #
G605866435
Country of Origin China
Category Power & General Purpose Relays
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- KUEP-7D15-24
- Zoro #
- G605866435
- UPC #
- -
- Country of Origin
- China
Details
- Item
- Power Relay
- Mounting Style
- Socket
- Electrical Connection
- Quick Connect, Solder
- Number of Pins
- 2
- Coil Voltage
- 24V DC
- Current Rating
- 10 A
- Contact Rating (DC)
- 10A @ 150V DC
- Number of Poles
- 2
- Features
- UL Coil Insulation Class B; Magnetic Blowout
- Power Consumption - Relay
- 1800 mW
- Contact Material
- AgCdO
- Coil Type
- Monostable, DC
- Coil Resistance
- 320 Ω
- Contact Limiting Short-Time Current
- 10A
- Contact Voltage Rating
- 150V DC
- Switching Current
- 300mA @ 12V
- Contact Limiting Breaking Current
- 10A
- Operating Temp. Range
- 50 to 70°C
- Contact Limiting Continuous Current
- 10A
- Contact Rating
- 10A
- Dielectric Voltage
- 2200 Vrms Adjacent Contacts; 2200 Vrms Coil and Contact; 1200 Vrms Open Contacts
- Contact Limiting Making Current
- 10A
- Protection Category
- RTI
Description
Power/Signal Relay, 2 Form A, Dpst, Momentary, 0.075A (Coil), 24Vdc (Coil), 1800Mw (Coil), 10A (Contact), 150Vdc (Contact), Dc Input, Ac/Dc Output, Panel Mount
