- MFR #
- SYS-5038A-IL
- Zoro #
- G6722092
- UPC #
- 672042138937
- Country of Origin
- Unknown
- Item
- Server Barebone System
- Standards
- ACPI 1.0 / 2.0
- Features
- Environmentally Friendly
- Color
- Black
- Includes
(1) Super X10SAE Motherboard, (1) 3U Mid-Tower Chassis, (4) SATA CABLE 61CM FLAT S-S PBF. 26AWG flat, 1x PS2 ATX 500W MULTI-OUTPUT HI-EFF PWS, (1) ROUND 16 pin TO 16 PIN RIBBON FP CABLE 30, 1 xFront control cable 16 pin split, 6, (1) USB 3.0 Internal Cable-60 cm(19 pin Female to 19pin Female), (1) HD/AC97 Audio Cable-60cm, (1) 12 CM x12 CM fan, (4) SC731 Tool-less Internal 3.5inch HDD Tray, (1) SC731 Card Reader Rail
- Mounting
- Mid-tower
- Input Voltage
- 110V AC, 220V AC
- Audio Line Out
- Yes
- Number of USB 2.0 Ports
- 10
- RAID Levels
- 0, 1, 5, 10
- DisplayPort
- Yes
- Number of PCI Express x16 Slots
- 2
- DVI
- Yes
- Number of Power Supplies Installed
- 1
- HDMI
- Yes
- Number of Expansion Slots
- 7
- Processor Socket
- Socket H3 LGA-1150
- Number of Total Expansion Bays
- 6
- VGA
- Yes
- Controller Type
- Serial ATA/600
- Max. Power Supply Wattage
- 500 W
- Number of Total Memory Slots
- 4
- Processor Supported
- Pentium, Core i3, Xeon, Celeron, Core i7, Core i5
- Max. Memory Supported
- 32 GB
- Memory Standard
- DDR3-1600/PC3-12800
- Number of USB Ports
- 16
- Number of Processors Supported
- 1
- Number of PCI Slots
- 2
- Number of PCI Express x1 Slots
- 3
- Number of SATA Interfaces
- 8
- Audio Line In
- Yes
- RAID Supported
- Yes
- Ethernet Technology
- Gigabit Ethernet
- Memory Technology
- DDR3 SDRAM
- Network (RJ-45)
- Yes
- Number of USB 3.0 Ports
- 6
- Chipset Manufacturer
- Intel
- Number of External 5.25" Bays
- 1
- Green Environmental Attribute
- Environmentally Friendly
- Chipset Model
- C226 Express
- Number of Memory Slots
- 4
- Number of 3.5" Bays
- 5
