- Voltage
- 230V AC, 120V AC
- Color
- Black
- Includes
1 x Super X10DRG-H Motherboard, 1 x CSE-118GH-R1K66B Chassis, 1 x Air Shroud for Air X9DRG/X10DRG boards in CSE-118GH-R1K66B, 1 x SAS-118G-4; supports 4X2.5" SATA HDD,, 1 x 8 pin to 8 pin ribbon SGPIO cable with tube, 27cm, PBF, 1 x 8 Pin to Two 4 Pin Backplane Power Ext. 28/22cm. 18AWG, 3 x 8 pin to two 6+2 pin 12V GPU power cable, 30 cm 16/20 AWG,HF,RoHS/REACH,PBF, 4 x 55cm 30AWG SATA S-S cable, 5 x 4 pin to 4 pin fan extension cord, for PWM fan. 23cm. 24AWG, 1 x (Riser Card) R1UG-E16R+II, 1 x (Riser Card) RSC-R1UG-A2E16-X9, 1 x (Riser Card) R1UG-E16AR+II, 1 x (Riser Card) RSC-R1UG-E16-X9, 1 x 1U Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB, 1 x 1U Passive Front CPU Heat Sink w/ a Side Air Channel for X9, X10 Systems Equipped with a Narrow ILM MB, 2 x 1U 1600W Redundant Platinum Power Supply 73.5mm width,RoHS/REACH,PBF, 2 x NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt), 10 x 40x40x56 mm 20.5K RPM / 17.6K RPM Counter-rotating Fan, 4 x Black gen 3rd hot-swap 2.5inch HDD tray, 1 set Rail set, quick/quick, optional for 1U 17.2
- Features
- 64-bit Processing; Environmentally Friendly; Network (RJ-45); QuickPath Interconnect Supported; RAID Supported; VGA
- Standards
- ACPI 1.0, ACPI 2.0, ACPI 3.0
- QuickPath Interconnect
- 9.60 GT/s
- Number of SATA Interfaces
- 10
- Number of USB 3.0 Ports
- 4
- Number of PCI Express x16 Slots
- 5
- Memory Technology
- DDR4 SDRAM
- Mounting
- Rack
- Total Number of USB Ports
- 6
- Graphics Controller
- ASPEED; AST2400
- Number of Processors Supported
- 2
- Processor Supported
- Xeon
- Number of Expansion Slots
- 5
- Number of Memory Slots
- 16
- Item
- Server Barebone System
- Chipset
- Intel C612 Express
- Maximum Memory Supported
- 1 TB
- Ethernet Technology
- Gigabit Ethernet
- Number of Total Expansion Bays
- 4
- Number of USB 2.0 Ports
- 2
- Number of Power Supplies Installed
- 2
- Controller Type
- Serial ATA/600
- Memory Standard
- DDR4-2133/PC4-17000
- Maximum Power Supply Wattage
- 1600 W
- Processor Socket
- Socket LGA 2011-v3
- RAID Levels
- 0, 1, 5, 10
- Green Environmental Attribute
- Environmentally Friendly
- Graphics Controller Model
- AST2400
- QuickPath Interconnect Supported
- Yes
- Chipset Model
- C612 Express
- Chipset Manufacturer
- Intel
- Number of USB Ports
- 6
- Network (RJ-45)
- Yes
- RAID Supported
- Yes
- Graphics Controller Manufacturer
- ASPEED
- Max. Memory Supported
- 1 TB
- VGA
- Yes
- 64-bit Processing
- Yes
- Max. Power Supply Wattage
- 1600 W
