- MFR #
- SYS-1028R-WC1R
- Zoro #
- G6253957
- UPC #
- 672042157471
- Country of Origin
- Unknown
- Voltage
- 230V AC, 120V AC
- Standards
- ACPI 1.0, ACPI 2.0, ACPI 3.0, ACPI 4.0
- Color
- Black
- Includes
1 x Super X10DRW-i Motherboard, 1 x 1U Chassis, 1 x Backplane support 8x 2.5" SAS2/SAS3/SATA3 HDD/SSD on device ID[1-8], with SGPIO. Support 2x 2.5" PCIe NVMe SSD on device ID[9-10] - with PCIe x1,x2,x4 support, max 25W/slot.,RoHS/REACH,PBF, 1 x Internal Mini-SAS HD to Mini-SAS HD 35cm,30AWG,12Gb/s,HF,RoHS/REACH,PBF, 1 x 8 pin to 8 pin round SGPIO cable, 61.5cm, 28AWG, pinout 1-1,RoHS/REACH, 2 x 55cm 30AWG SATA S-S cable, 1 x Internal Mini-SAS HD to Mini-SAS HD 25cm,30AWG,HF,RoHS/REACH,PBF, 1 x RSC-R1UW-2E16-O-P, 1 x 1U Passive Front CPU Heat Sink w/ a Side Air Channel for X9, X10 Systems Equipped with a Narrow ILM MB, 1 x 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB, 2 x 1U 750W redundant power width 54.5mm(Platinum),HF,RoHS/REACH,PBF
- Features
- 64-bit Processing; Environmentally Friendly; Network (RJ-45); QuickPath Interconnect Supported; RAID Supported; VGA
- QuickPath Interconnect
- 9.60 GT/s
- Item
- Server Barebone System
- RAID Levels
- 0, 1, 5, 6, 10, 50, 60
- Power Supply
- 750 W
- Controller Type
- 12Gb/s SAS, Serial ATA/600
- Number of PCI Express x16 Slots
- 2
- Number of Processors Supported
- 2
- Number of SATA Interfaces
- 2
- Mounting
- Rack
- Number of SAS Interfaces
- 8
- Number of USB 3.0 Ports
- 6
- Processor Socket
- Socket LGA 2011-v3
- Memory Standard
- DDR4-2133/PC4-17000
- Number of Expansion Slots
- 2
- Processor Supported
- Xeon
- Number of USB Ports
- 6
- Ethernet Technology
- Gigabit Ethernet, Fast Ethernet
- Number of Internal 2.5" Bays
- 10
- Number of Total Expansion Bays
- 10
- Number of Power Supplies Installed
- 2
- Maximum Memory Supported
- 1 TB
- Memory Technology
- DDR4 SDRAM
- Number of Total Memory Slots
- 16
- VGA
- Yes
- Max. Power Supply Wattage
- 750 W
- Green Environmental Attribute
- Environmentally Friendly
- Chipset Manufacturer
- Intel
- QuickPath Interconnect Supported
- Yes
- RAID Supported
- Yes
- Graphics Controller Model
- AST2400
- Graphics Controller Manufacturer
- ASPEED
- Number of Memory Slots
- 16
- Max. Memory Supported
- 1 TB
- Chipset Model
- C610
- 64-bit Processing
- Yes
- Network (RJ-45)
- Yes
