- MFR #
- SYS-2028R-C1R4+
- Zoro #
- G6265595
- UPC #
- 672042163373
- Country of Origin
- Unknown
- Voltage
- 230V AC, 120V AC
- Color
- Black
- Includes
1 x Super X10DRC-LN4+ Motherboard, 1 x 2U Black SC218G Chassis, 1 x SAS3 backplane with 16x 2.5" drive bays, for CSE-213AC chassis, support SGPIO SES2 management and have 4x Mini-SAS HD connectors,RoHS/REACH,PBF, 2 x Internal Mini-SAS HD to Mini-SAS HD 35cm,30AWG,12Gb/s,HF,RoHS/REACH,PBF, 2 x cross-over mini SAS HD to 4 SATA w/SB, S. 55cm. 30AWG,RoHS/REACH, 2 x RA to S mini SAS HD 12Gb/s, 40cm, 30AWG,HF,RoHS/REACH,PBF, 2 x cross-over mini SAS HD to 4 SATA w/SB, S. 75cm. 30AWG,HF,RoHS/REACH,PBF, 2 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Square ILM MB, 2 x 1U REDUNDANT 920W PMBus 94% EFFICIENCY, 3 x 10.5" , 4 PIN MIDDLE FAN POWER EXTENSION (PWM), 1 x 16 pin control panel converter cable for SC826,846, 22cm, PBF, 1 x ROUND 16 pin TO 16 PIN RIBBON FP CABLE 30, 3 x 80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing, 1 x Black 5.25, 1 x Black USB dummy tray support 1x 2.5" slim HDD for SC825, 836, 16 x Black gen 3rd hot-swap 2.5inch HDD tray, 1 x Rail set, quick/quick, default for 2,3U 17.2\"W
- Features
- 64-bit Processing; Environmentally Friendly; Network (RJ-45); QuickPath Interconnect Supported; RAID Supported; VGA
- Standards
- ACPI 1.0, ACPI 2.0
- Ethernet Technology
- Gigabit Ethernet
- Number of PCI Express x8 Slots
- 4
- Number of Power Supplies Installed
- 2
- Item
- Server Barebone System
- Number of Processors Supported
- 2
- Number of USB 2.0 Ports
- 4
- Memory Technology
- DDR4 SDRAM
- Number of Internal 2.5" Bays
- 16
- Processor Socket
- Socket LGA 2011-v3
- Processor Supported
- Xeon
- Controller Type
- Serial ATA/600, 12Gb/s SAS
- Number of USB 3.0 Ports
- 2
- QuickPath Interconnect
- 9.60 GT/s
- Number of SAS Interfaces
- 8
- RAID Levels
- 0, 1, 5, 6, 10, 50, 60
- Number of Total Memory Slots
- 24
- Number of Expansion Slots
- 6
- Number of USB Ports
- 7
- Power Supply
- 920 W
- Number of PCI Express x16 Slots
- 2
- Number of SATA Interfaces
- 10
- Number of Total Expansion Bays
- 16
- Memory Standard
- DDR4-2133/PC4-17000
- Mounting
- Rack
- Maximum Memory Supported
- 1.5 TB
- Chipset Manufacturer
- Intel
- Green Environmental Attribute
- Environmentally Friendly
- QuickPath Interconnect Supported
- Yes
- RAID Supported
- Yes
- Network (RJ-45)
- Yes
- Graphics Controller Model
- AST2400
- Max. Power Supply Wattage
- 920 W
- Graphics Controller Manufacturer
- ASPEED
- Max. Memory Supported
- 1.50 TB
- Chipset Model
- C612 Express
- VGA
- Yes
- 64-bit Processing
- Yes
- Number of Memory Slots
- 24
