- MFR #
- SYS-2028TP-HTR
- Zoro #
- G6252548
- UPC #
- 672042162178
- Country of Origin
- Unknown
- Voltage
- 230V AC, 120V AC
- Color
- Black
- Features
- 64-bit Processing; Environmentally Friendly; RAID Supported
- Standards
- ACPI 1.0 / 2.0
- Includes
4 x Super X10DRT-P Motherboards, 1 x 2U Chassis, 1 x ,RoHS/REACH,PBF 2U Twin Square Backplane, support 24 SAS3/SATA3 HDD (2.5") with Hot Swapping. Per node for 6 HDDs. PWM fan control, HDD spin up and failure LED supported., 4 x Backplan adapter card; 6SATA ports,RoHS/REACH,PBF, 4 x ,RoHS/REACH,PBF, 4 x 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Narrow ILM MB, 4 x 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers, 2 x 2000W Redundant Platinum Power Supply
- Number of USB 3.0 Ports
- 2
- Number of Expansion Slots
- 1
- Item
- Server Barebone System
- Processor Socket
- Socket LGA 2011-v3
- Number of SATA Interfaces
- 6
- Controller Type
- Serial ATA/600
- Number of Processors Supported
- 2
- Power Supply
- 2000 W
- Number of Nodes
- 4
- Memory Technology
- DDR4 SDRAM
- Maximum Memory Supported
- 1 TB
- Ethernet Technology
- Gigabit Ethernet, Fast Ethernet
- Processor Supported
- Xeon
- Number of Internal 2.5" Bays
- 6
- Number of USB Ports
- 2
- Memory Standard
- DDR4-2133/PC4-17000
- Number of Power Supplies Installed
- 2
- Number of Total Memory Slots
- 16
- Mounting
- Rack
- Number of PCI Express x16 Slots
- 1
- Graphics Controller Manufacturer
- ASPEED
- Number of Memory Slots
- 16
- Green Environmental Attribute
- Environmentally Friendly
- Graphics Controller Model
- AST2400
- RAID Supported
- Yes
- Max. Memory Supported
- 1 TB
- Chipset Model
- C612 Express
- 64-bit Processing
- Yes
- Max. Power Supply Wattage
- 2000 W
- Chipset Manufacturer
- Intel
