- Voltage
- 230V AC, 120V AC
- Features
- 64-bit Processing; Environmentally Friendly; Network (RJ-45); QuickPath Interconnect Supported; RAID Supported; VGA
- Standards
- ACPI 1.0, ACPI 2.0
- Color
- Black
- Includes
1 x Super X10DRH-C Motherboard, 1 x 4U Chassis, 1 x RoHS/REACH,PBF SAS3 BPN - 8x2.5" SSD/HDD hotswap drive bays for CSE-M28SAC chassis,overheat indicator,SGPIO support SES2 mngt,2 mini-SAS HD connector(SFF-8643),1 fan connector with fan fail detection, 1 x CSE-SAS-743TQ-O-P, 1 x 8 pin to 8 pin round SGPIO cable, 40cm, 28AWG, pinout 1-1,RoHS/REACH, 1 x IPASS to 4 SATA, 55,45,35,30, w/55 SB, 30AWG, 4 x 55cm 30AWG SATA S-S cable, 2 x Internal Mini-SAS HD to Mini-SAS HD 50cm,30AWG,12Gb/s,HF,RoHS/REACH,PBF, 1 x Power extension cable; one HDD to two HDD and two FDD. 35/25/12cm. 22AWG, 2 x 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Narrow ILM MB, 2 x 1U REDUNDANT 920W PMBus 94% EFFICIENCY, 1 x Black SAS3/SATA3 Mobile Rack for 8x 2.5" HDD w/o fan module,HF,RoHS/REACH,PBF
- Number of SATA Interfaces
- 8
- Number of Processors Supported
- 2
- Processor Supported
- Xeon
- Number of PCI Express x8 Slots
- 6
- Number of PCI Express x16 Slots
- 1
- Number of USB Ports
- 7
- Number of External 5.25" Bays
- 1
- RAID Levels
- 0, 1, 5, 6, 10, 50, 60
- Ethernet Technology
- Gigabit Ethernet
- Controller Type
- Serial ATA/600, 12Gb/s SAS
- Maximum Memory Supported
- 1 TB
- Item
- Server Barebone System
- Power Supply
- 920 W
- Number of Total Memory Slots
- 16
- Number of 3.5" Bays
- 8
- Number of USB 2.0 Ports
- 4
- QuickPath Interconnect
- 9.60 GT/s
- Number of Expansion Slots
- 7
- Number of Internal 2.5" Bays
- 8
- Mounting
- Tower
- Processor Socket
- Socket LGA 2011-v3
- Memory Standard
- DDR4-2133/PC4-17000
- Number of Power Supplies Installed
- 2
- Memory Technology
- DDR4 SDRAM
- Number of USB 3.0 Ports
- 2
- Number of Total Expansion Bays
- 17
- Number of SAS Interfaces
- 8
- Chipset Manufacturer
- Intel
- Graphics Controller Model
- AST2400
- Network (RJ-45)
- Yes
- QuickPath Interconnect Supported
- Yes
- VGA
- Yes
- Green Environmental Attribute
- Environmentally Friendly
- Max. Memory Supported
- 1 TB
- Graphics Controller Manufacturer
- ASPEED
- Number of Memory Slots
- 16
- 64-bit Processing
- Yes
- Chipset Model
- C612 Express
- Max. Power Supply Wattage
- 920 W
- RAID Supported
- Yes
