This item is Discontinued.

Telemecanique Sensors Photo-electric sensor-XUV-fork-80X XUVR0608PBNM8

Photo-electric sensor-XUV-fork-80X (Discontinued)

  • Mfr # XUVR0608PBNM8
  • Zoro # G400905254
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
XUVR0608PBNM8
Zoro #
G400905254
UPC #
-
Country of Origin
France

Dimensions

Spot Diameter
0.03 in (0.8 mm)
Passage Width
80 mm
Passage Depth
60 mm

Details

Item
Photo-electric sensor - XUV - fork - 80X
Material
metal/plastic
Electrical Connection
1 male connector M8, 3 pins
Current Consumption
< 20 mA no-load
Sensor Name
XUVR
Series Name
general purpose
Maximum Voltage Drop
<1.5 V closed state)
Enclosure Material
painted aluminium and polyamide/glass
Immunity To Ambient Light
10000 lux natural light || 5000 lux incandescent bulb
Ambient Air Temperature For Operation
-10-60°C
[Us] Rated Supply Voltage
12...24 V DC reverse polarity protection
Sensor Design
fork
Discrete Output Type
PNP
Wiring Technique
3-wire
Type Of Output Signal
discrete
Product Certifications
UL || CSA || CE
[Sn] Nominal Sensing Distance
80-80 mm
Supply Circuit Type
DC
Status Led
output state 1 LED yellow)
Switching Capacity In Ma
100 mA overload and short-circuit protection)
Shock Resistance
30 gn 11 ms) IEC 60068-2-27
Vibration Resistance
7 gn +/- 0.75 mm 10-55 Hz) IEC 60068-2-6
Product Specific Application
detection on small conveyor
Ambient Air Temperature For Storage
-40-80°C
Supply Voltage Limits
10-30 V DC
Detection System
thru beam
Output Type
solid state
Electronic Sensor Type
photo-electric sensor
Discrete Output Function
1 NC
Switching Frequency
4000 Hz
Emission
red LED, modulated
Ip Degree Of Protection
IP65 || IP67

Description

Photo-electric sensor - XUV - fork - 80X
