- MFR #
- XUVU06M3KSNM8
- Zoro #
- G0671730
- UPC #
- -
- Country of Origin
- France
- Item
- Ultrasonic Label Sensor Pnp Npn M8 4P
- Electrical Connection
- 1 male connector M8, 4 pins
- Enclosure Material
- zinc alloy
- Material
- metal
- Accuracy
- +/- 0.20 mm 120 m/min
- Maximum Delay Response
- 0.3 ms
- Product Specific Application
- detection of transparent labels
- Type Of Setting
- without
- Emission
- ultrasonic
- Switching Frequency
- <= 1500 Hz
- Ip Degree Of Protection
- IP65 IEC 60529
- Ambient Air Temperature For Storage
- -20-70°C
- [Us] Rated Supply Voltage
- 12...24 V DC reverse polarity protection
- Lens Material
- PC
- Shock Resistance
- 30 gn 11 ms) IEC 60068-2-27
- Sensor Name
- XUV
- Output Type
- solid state
- Supply Voltage Limits
- 10-30 V DC
- Electronic Sensor Type
- photo-electric sensor
- Vibration Resistance
- 7 gn +/- 1.5 mm 10-55 Hz) IEC 60068-2-6
- Sensor Design
- fork
- Setting-Up
- numeric potentiometer
- Switching Capacity In Ma
- <= 100 mA overload and short-circuit protection)
- Maximum Delay First Up
- 30 ms
- Product Certifications
- cULus || CE
- Discrete Output Type
- PNP and NPN
- Discrete Output Function
- 2 NO/NC programmable
- Supply Circuit Type
- DC
- Minimum Distance Between Labels
- 2 mm
- Detection System
- thru beam
- Type Of Output Signal
- discrete
- Ambient Air Temperature For Operation
- 5-55°C
- Wiring Technique
- 4-wire
- Series Name
- Application packaging
- [Sn] Nominal Sensing Distance
- 3-3 mm thru beam
- Maximum Voltage Drop
- <2 V closed state)
- Status Led
- output state 1 LED yellow) || adjustment mode and keypad locking 1 LED red)
- Maximum Delay Recovery
- 0.3 ms
- Maximum Passing Speed Of Object
- 180 m/min
