Epoxy Adhesive, DP820 Series, Black, Dual-Cartridge, 1:01 Mix Ratio, 40 min Functional Cure

  • Mfr # 820

  • Zoro # G1618055


product price: $55.45
/ea

Key Features

Type
Medium Viscosity
Application
For The Structural Bonding
Color
Black
For Use On
3M(TM) Dispensing Equipment
Container Type
Dual-Cartridge
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
820
Zoro #
G1618055
UPC #
00638060089774
Country of Origin
United States

Dimensions

Size
1.5 oz

Details

Item
Epoxy Adhesive
Type
Medium Viscosity
Application
For The Structural Bonding
Color
Black
For Use On
3M(TM) Dispensing Equipment
Container Type
Dual-Cartridge
Functional Cure
40 min
Full Cure
48 hr
Mixing Ratio
1:01
Shear Strength
3,600 psi
Temp. Range
73 Degrees to 175 Degrees
Working Time
15 min
Series
DP820
Work Life
15 min
Coverage
320 sq ft/gal
Structural Adhesive Type
Acrylic Adhesive
Epoxy Color
Off-White
Includes
Resin and Hardener
Temp. Range (F)
73 Degrees to 175 Degrees
Green Environmental Attribute
Does Not Contain Methylene Chloride
For Use With
3M(TM) Dispensing Equipment
Epoxy Container
Dual-Cartridge
Shear Strength (PSI)
3,500
Application Method
No Special Application
Resin Type
Acrylic
Marine Grade
No
Cured Color
Light Yellow
Standards
OSHA 29 CFR 1910.1200, TSCA
VOC Content Weight Percentage
0.5%
Primary Applications
Metals
Maximum Application Temperature
80 Degrees F
Cure Method
Ambient
Minimum Viscosity
45,000 cps
Total Volume
48.5 mL
Hardener Color
Yellow
Maximum Performance Temperature
180 Degrees F
Full Cure Time
48 hr
Minimum Performance Temperature
73 Degrees F
Alternate Product Name
3M Scotch-Weld Acrylic Adhesive DP820
Maximum Viscosity
70,000 cps
VOC Content Weight
4.9 g/L
Compatible Applicator (Grainger Part Number)
54XK02
Included Components
Resin and Hardener
Compatible Mixer Tip
7100104991
Water Resistance
Water-Resistant
Materials Bonded
Ceramic, Glass, Metal, Plastic, Rubber, Wood
Resin Color
Off-White
Peel Strength
35 lb/in
Low Odor
No
Compatible Applicator
3M EPX
Hardness at Full Cure
75 Shore D
Non-Sagging
Yes
Tensile Strength
3,200 psi
Features
Chemical Resistant, Humidity Resistant
Interior/Exterior
Interior/Exterior
Compatible Primer
EC-3901 for Glass
Container Type - Adhesives
Dual-Cartridge

Description

Acrylic Adhesive, Compatible Applicator 3M EPX, Compatible Mixer Tip 7100104991, Compatible Primer EC-3901 for Glass, Container Type Dual-Cartridge, Coverage 320 sq ft/gal, Cure Method Ambient, Cured Color Light Yellow, Features Chemical Resistant, Humidity Resistant, For Use With Applicator, Mixing Tip, Included Components Resin and Hardener, Interior/Exterior Interior/Exterior, Low Odor No, Marine Grade No, Materials Bonded Ceramic, Glass, Metal, Plastic, Rubber, Wood

Restrictions

Hazardous material
