  5. Epoxy Adhesive, Gray, 5/8 in Dia, 2 in L, 45 sec Begins to Harden, 528 PK
3M Epoxy Adhesive, Gray, 5/8 in Dia, 2 in L, 45 sec Begins to Harden, 528 PK 3748 TC - main

Epoxy Adhesive, Gray, 5/8 in Dia, 2 in L, 45 sec Begins to Harden, 528 PK

  • Mfr # 3748 TC

  • Zoro # G5932534

product price:  $461.99
/pk 528, $0.87/ea
Free Shipping & Returns

Key Features

Product Form
Smooth Sticks
Diameter
5/8 in
Length
2 in
Materials Bonded
Fabric, Foam, Metal, Plastic, Vinyl, Wood
Working Time
45 sec
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
3748 TC
Zoro #
G5932534
UPC #
00021200825842
Country of Origin
United States

Dimensions

Diameter
5/8 in
Length
2 in
Diameter - Glue Sticks
5/8 in
Length - Glue Sticks
2 in
Compatible Applicator Size
TC

Details

Item
Epoxy Adhesive
Product Form
Smooth Sticks
Materials Bonded
Fabric, Foam, Metal, Plastic, Vinyl, Wood
Working Time
45 sec
Melting Temperature
350 Degrees to 385 Degrees F
Begins to Harden
45 sec
Color
Gray
Electrically Insulating
No
High Tack
No
Series
3748
Melting Temp. - Glues
175 Degrees F
Tensile Strength
375 psi
Shear Strength
250 psi
Peel Strength
18 psi
For Use With
Mfr. No. POLYGUN TC
Application
Attaching Components on PC Boards, Cable Strain Relief, Coil Terminating, Potting, Product Assembly, Rigidizing Components, Wire Fastening
Full Cure
24 hr
Temp. Range
-20 to 250 Degrees
Characteristics
Good Thermal Shock Resistance, Non Corrosive to Copper for Many Electrical Applications
Substrates
Polyolefin
Green Environmental Attribute
Does Not Contain Methylene Chloride
Open Time
45 sec
Features
100% Solids, Fuel and Oil Resistant, Heat Resistant, High Temperature Stability, Impact Resistant, Low Temperature Thermal Shock Properties, Provides Optimal Adhesion In Fluctuating Temperatures, Thermoplastic Resin
Minimum Viscosity
5,000 cps
Pressure Sensitive
Yes
Product Format
Smooth Sticks
UV Resistant
No
Low Odor
No
Maximum Performance Temperature
250 Degrees F
Primary Applications
Low-Surface Energy Plastics
Full Cure Time
24 hr
Maximum Viscosity
5,000 cps
FDA Compliance
21 CFR 175.105
Minimum Performance Temperature
-20 Degrees F
Material
Fabric, Foam, Metal, Plastic, Vinyl, Wood
Container Type
Can
Full Cure Time - Adhesives
24 hr
Begins to Harden - Adhesives
45 sec

Description

Hot Melt Adhesive, Color Off-White, Diameter 5/8 in, Length 2 in, Melting Temperature 350 Degrees to 385 Degrees F, Product Format Smooth Sticks, Series 3748, Working Time 45 sec, Maximum Viscosity 5,000 cps, Minimum Viscosity 5,000 cps, Electrically Insulating No, FDA Compliance 21 CFR 175.105
