Female Disconnect, Red, 22-18AWG, PK1000
Mfr # MNU18-250DFIK
Zoro # G5618252
product price: $528.99
/pk 1000, $0.53/ea
Free Shipping & Returns
Key Features
Insulation
Full
Material
Plastic
Insulation Color
Red
Insulation Type
Nylon
Wire Range
22 to 18 AWG
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
MNU18-250DFIK
Zoro #
G5618252
UPC #
00054007022909
Country of Origin
United States
Dimensions
Overall Length
0.87 in
Tab Size
0.032 in x 0.250 in
Barrel Inside Dia.
0.08 in
Conductor Sizes
22 - 18 AWG
Maximum Insulation Outer Diameter
0.145 in
Length
0.87 Inch
Width
0.37 Inch
Diameter
0.23 Inch
Barrel Length
0.25 Inch
Male Tab Width (W')
0.25 Inch
Mates with Male Tab Width (W')
0.250 Inch
Pad Width
0.25 Inch
Thickness
0.032 Inch
Maximum Insulation Outside Diameter
0.145 in
Maximum Conductor Size
18 AWG
Tab Width
0.25 in
Minimum Conductor Size
22 AWG
Connection Width
0.25 in
Barrel Inside Diameter
0.08 in
Overall Diameter
0.23 in
Overall Width
0.37 in
Minimum Wire Size
22 AWG
Tab Thickness
0.032 in
Maximum Wire Size
18 AWG
Description
Wire Disconnect, Contact Finish Tin, Contact Material Brass, Disconnect Style Quick Disconnect, Insulation Color Red, Insulation Coverage Full Coverage, Insulation Material Nylon, Maximum Temperature 221 Degrees F, Minimum Wire Size 22 AWG, Maximum Wire Size 18 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Socket, Termination Style Crimp, UL 94 Flammability Rating V-2, Seam Style Butted, Standards CSA Certified, UL Listed, Barrel Inside Diameter 0.08 in
