Foil Tape, 3/4 In. x 18 Yd., Copper, PK12

  • Mfr # 1183, 3/4 in x 18 yd

  • Zoro # G5708561


product price:  $905.99
/pk 12, $75.50/ea
Free Shipping & Returns

Key Features

Tape Color
Silver
Series
1183
Tape Thickness
2.8 mil
Performance Temp.
-40 Degrees to 130 Degrees C
Tape Tensile Strength
25 lb/in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1183, 3/4 in x 18 yd
Zoro #
G5708561
UPC #
00051138498719
Country of Origin
Taiwan, Province of China

Dimensions

Tape Thickness
2.8 mil
Width
3/4"
Length
18 yd.
Thickness
2.60 mil
Tape Length
18 yd
Tape Width
3/4 in
Tape Core Diameter
3 in
Duct Tape Length
18 yd.
Duct Tape Thickness
2.6 mil
Duct Tape Width
3/4"
Metric Tape Width
19.1 mm
Imperial Tape Width
3/4 in
Metric Tape Length
16.5 m
Imperial Tape Length
54 ft
Imperial Tape WxL
3/4 in x 54 ft

Details

Tape Color
Silver
Series
1183
Performance Temp.
-40 Degrees to 130 Degrees C
Item
Conductive Electrical Tape
Tape Tensile Strength
25 lb/in
Color
Copper
Min. Tape Performance Temp.
-40 Degrees F
Tape Backing Material
Tin-Plated Copper
Tape Adhesive
Acrylic
Material
Copper Foil
Tape Adhesive Strength
35 oz/in
Adhesion Strength
35 oz./in.
Max. Tape Performance Temp.
265 Degrees F
Standards
RoHS 2011/65/EU, UL Listed
Shape
Continuous Roll
Tensile Strength
25 lb./in.
Tape Elongation
5 %
Adhesive
Acrylic
Tape Shape
Continuous Roll
Duct Tape Adhesive
Acrylic
Number of Adhesive Sides
1
Tape Backing Construction
Foil
Tape Adhesive Material
Acrylic
Product Form
Continuous Roll
Tape Type
Foil
Tape Adhesive Format
Single-Sided
Minimum Tape Performance Temperature
-40 Degrees F
Elongation
5 %
Tape Brand
3M(TM)
Maximum Tape Performance Temperature
266 Degrees F
Adhesion to Steel
35 oz/in
Breaking Strength
25 lb/in
Tape Sub-Type
General Purpose Foil
Shielding Effectiveness
Fair (50 to 70dB)
Voltage Rating
600 V
Tape Resistance Properties
Heat-Resistant, Oil-Resistant, Oxidation-Resistant, Solvent-Resistant
Specifications Met
EU, RoHS, UL Listed
Brand
3M(TM)

Description

Conductive Electrical Tape, Tape Backing Material Tin-Plated Copper, 3/4 in, 54 ft, Tape Color Silver, Tape Sub-Type General Purpose Foil, Tape Adhesive Material Acrylic, 2.8 mil, 3M(TM), 1183, Minimum Tape Performance Temperature -40 Degrees F, Maximum Tape Performance Temperature 266 Degrees F, Voltage Rating 600 V, Shielding Effectiveness Fair (50 to 70dB), Product Form Continuous Roll, Tape Adhesive Format Single-Sided, Package Quantity 12
