Shop 3M

Glue, DP805 Series, Clear, 1 gal, Dual-Cartridge, 1:01 Mix Ratio, 140 min Functional Cure

  • Mfr # DP805

  • Zoro # G7749434

product price:
$
49.15
/ea

Key Features

Application
Bonding
Type
Medium Viscosity
Application Method
No Special Application
Series
DP805
Container Type
Dual-Cartridge
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
DP805
Zoro #
G7749434
UPC #
00638060089828
Country of Origin
United States

Dimensions

Container Size
1 gal
Size
1.5 oz
Total Container Size
48.5 mL

Details

Item
Glue
Application
Bonding
Type
Medium Viscosity
Application Method
No Special Application
Series
DP805
Container Type
Dual-Cartridge
Coverage
320 sq ft/gal
Working Time
3 min
Functional Cure
140 min
Color
Clear
Mixing Ratio
1:1
Resin Type
Acrylic
Shear Strength
900 psi
Temp. Range
0 Degrees to 72 Degrees
Green Environmental Attribute
Does Not Contain Methylene Chloride
For Use With
Applicator, Mixing Tip
Includes
Resin and Hardener
Maximum Performance Temperature
180 Degrees F
Minimum Viscosity
75,000 cps
Compatible Primer
EC-3901 for Glass
Cure Method
Moisture
Water Resistance
Water-Resistant
Resin Color
Off-White
Hardener Color
Yellow
Total Volume
48.5 mL
Materials Bonded
Ceramic, Glass, Metal, Plastic, Rubber, Wood
Interior/Exterior
Interior/Exterior
Primary Applications
Metals
VOC Content Weight
4.9 g/L
Full Cure Time
24 hr
Cured Color
Yellow
Marine Grade
No
Included Components
Resin and Hardener
Compatible Applicator
3M EPX
Peel Strength
35 lb/in
Tensile Strength
3,200 psi
Non-Sagging
Yes
Minimum Application Temperature
0 Degrees F
Hardness at Full Cure
79 Shore D
Features
High Tensile Stength, Minimal Surface Preparation
Maximum Viscosity
150,000 cps
Low Odor
No
VOC Content Weight Percentage
0.5%
Standards
OSHA 29 CFR 1910.1200, TSCA
Compatible Mixer Tip
7100104991
Maximum Application Temperature
80 Degrees F
Alternate Product Name
3M Scotch-Weld Acrylic Adhesive DP805
Adhesive Color
Off-White
Compatible Surface Material
Composites, Metal, Oily Metals, Plastic
For Marine Applications
Not Specified Marine Grade
Compatible Primer Manufacturer Part Number
EC-3901 for Glass
Tensile Strength - Maximum
4,500 psi
Compatible Mixer Tip Manufacturer Part Number
7100104991
Resistance Properties
Water-Resistant
Full Cure Time - Maximum
24 hr
Hardness at Full Cure - Minimum
79 Shore D
Compatible Applicator Manufacturer Part Number
EPX APPL

Description

Acrylic Adhesive, Compatible Applicator 3M EPX, Compatible Mixer Tip 7100104991, Compatible Primer EC-3901 for Glass, Container Type Dual-Cartridge, Coverage 320 sq ft/gal, Cure Method Ambient, Cured Color Yellow, Features High Tensile Stength, Minimal Surface Preparation, For Use With Applicator, Mixing Tip, Included Components Resin and Hardener, Interior/Exterior Interior/Exterior, Low Odor No, Marine Grade No, Materials Bonded Ceramic, Glass, Metal, Plastic, Rubber, Wood
