One-Hole Compression Lug, 1 AWG Max, 3/8 in Stud, Short Barrel, Copper, Green, 100 PK
- Mfr # MC1-38RX
- Zoro # G5878065
product price:Â
$
693.99
/pk of 100, $6.94/ea
Free Shipping & Returns
Key Features
For Wire Size
1 AWG
For Conductor Material
Copper
For Stud Size
3/8 in
Material
Copper
Barrel Size
Short
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- MC1-38RX
- Zoro #
- G5878065
- UPC #
- 00054007091929
- Country of Origin
- United States
- Item
- One-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Tongue Angle
- Straight
- Inspection Hole
- No
- Die Code
- 11
- Color Code
- Green
- Standards
- CSA Certified, UL Listed
- Plate Material
- Tin
- Connector Type
- Seamless Barrel
- Tongue Style
- Ring
- Peep Hole
- No
- Hole Center to End
- 0.4 in
- Seam Style
- Seamless
- Barrel Style
- Seamless
- RoHS Compliant
- Yes
- Contact Finish
- Tin
- Termination Style
- Crimp
- For Wire Type
- Stranded
- Special Features
- Non-Insulated Construction
- Shell Material
- Copper
- Traction Material
- Copper
Dimensions
- For Wire Size
- 1 AWG
- For Stud Size
- 3/8 in
- Barrel Size
- Short
- Tongue Width
- 0.68 in
- Width
- 0.68 in
- Barrel Length
- Short
- Length
- 1.71"
- Cable Size
- 1 AWG
- Length (Straight Wireway)
- 1.83 in
- Overall Length
- 1.71 in
- Tongue Length
- 1.23 in
- Strip Length
- 5/8 in
- For Stranded Copper Wire Size - Maximum
- 1 AWG
- Barrel Inside Diameter
- 0.36 in
- Overall Width
- 0.68 in
- Tongue Thickness
- 0.1 in
- Wire Rope Length
- 1.71 in
Description
Compression Lugs, Barrel Size Standard, Color Code Green, Die Code 11, Tongue Angle Straight, Tongue Width 0.68 in, For Conductor Material Copper, For Stud Size 3/8 in, For Stranded Copper Wire Size - Maximum 1 AWG, Inspection Hole No, Hole Center to Center Not Applicable, Material Copper, Termination Style Crimp, Seam Style Seamless, Standards CSA Certified, UL Listed, Number of Holes 1, RoHS Compliant Yes, Barrel Inside Diameter 0.36 in, Barrel Style Seamless, Connector Type Straight Barrel
