  13. A210-30-11-84, A210 3P CONTR 110/50 110-120/60
Abb A210-30-11-84, A210 3P CONTR 110/50 110-120/60 A210-30-11-84 - main

A210-30-11-84, A210 3P CONTR 110/50 110-120/60

  • Mfr # A210-30-11-84

  • Zoro # G9283752

product price: $3,892.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NC/1NO
Coil Voltage
110V-120V AC
Terminal Connection Type
Screw
Mechanical Durability
5 Mcycles
Working Height
3000 m
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
A210-30-11-84
Zoro #
G9283752
UPC #
66201987980
Country of Origin
Unknown

Dimensions

Working Height
3000 m
Overall Depth
180.5 mm
Overall Height
227 mm
Overall Width
140 mm

Details

Auxiliary Contact Form
1NC/1NO
Coil Voltage
110V-120V AC
Terminal Connection Type
Screw
Mechanical Durability
5 Mcycles
Hold VA
60 VA (at 50 Hz), 65 VA (at 60 Hz)
IP Rating
IP00, IP20
Impulse Withstand Voltage
8 kV
Operating Time
7 to 13 ms (Coil De-energization and NC Contact Closing), 10 to 16 ms (Coil De-energization and NO Contact Opening), 12 to 30 ms (Coil Energization and NC Contact Opening), 17 to 35 ms (Coil Energization and NO Contact Closing)
Rated Insulation Volts
600/1000V
Max. Operating Watts
110 kW (at 380/400V, 415V, 440V), 132 kW (at 500V), 160 kW (at 690V), 59 kW (at 220/230/240V)
Control Circuit Voltage Limits
0.85 to 1.1 Uc
Rated Short-Time Withstand Current
1700 A (at 40°C for 10 s), 400 A (at 40°C for 15 min), 1000 A (at 40°C for 1 min), 2500 A (at 40°C for 1 s), 1200 A (at 40°C for 30 s)
Net Weight
5.4 kg
Horsepower @ Three Phase - 240V AC
75 hp
Horsepower @ Three Phase - 208V AC
60 hp
Horsepower @ Three Phase - 480V AC
150 hp
Maximum Voltage Rating
690V
Conventional Free Air Thermal Current
350 A (at 40°C)
Frequency
50/60 Hz

Description

ABB A210-30-11-84 is an IEC magnetic contactor with three poles (3P) designed to switch three-phase power. It uses a coil rated within the specified coil voltage range, is compatible with systems operating at 50/60 Hz and within the specified voltage ranges, and contains auxiliary contacts configured as normally closed and normally open (1NC/1NO). The unit has a compact form factor with dimensions of 180.5 mm (depth) × 140 mm (width) × 227 mm (height) and a net weight of 5.4 kg. Wiring is via screw terminals and bars for electrical connection, and the enclosure ratings conform to IP00 and IP20 standards for electrical enclosures.

Key features

  • Coil Voltage: rated within the specified coil voltage range
  • Auxiliary Contacts: configured as normally closed and normally open (1NC/1NO)
  • Control Circuit Voltage Limits: are within the specified range of 0.85 to 1.1 times the coil nominal voltage
  • Depth × Width × Height: 180.5 mm × 140 mm × 227 mm
  • Electrical Connection: Bars
  • Terminal Connection Type: Screw
  • Enclosure Ratings: conform to IP00 and IP20 standards for electrical enclosures
  • Withstand: withstands impulse voltages up to standard test levels; actual performance may vary based on installation conditions
  • Rated Voltage: rated for operation within specified voltage ranges up to approximately 690 V under normal conditions
  • Rated Insulation Volts: 600/1000 V
  • Mechanical Durability: designed for an expected mechanical lifespan based on typical usage cycles; actual durability may vary depending on application conditions
  • Net Weight: 5.4 kg
  • Operational response times: are within typical industry ranges for similar devices; actual timing may vary depending on system conditions
  • Hold VA: power consumption specifications provided under standard testing conditions; actual values depend on application parameters
  • Power ratings: are based on standardized testing conditions; actual performance depends on system configuration and load characteristics
  • Hz: 50/60 Hz
  • Working Height: 3000 m
  • Max Operating Watts: 110 kW (380/400/415/440 V), 132 kW (500 V), 160 kW (690 V)
