Locking Connector, L6-30R, 30 A, 250V AC, Single Phase, Screw Terminals, Yellow
Mfr # ASL630R
Zoro # G410113168
product price: $24.29
/eaSold in multiples of 2 for $48.58
Key Features
NEMA Receptacle Configuration
L6-30R
Current Rating
30 A
Voltage Rating
250V AC
Phase
Single
Number of Wires
3
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
ASL630R
Zoro #
G410113168
UPC #
819145020640
Country of Origin
Taiwan, Province of China
Dimensions
For Maximum Cable Diameter
1.125 in
Details
Item
Locking Connector
NEMA Receptacle Configuration
L6-30R
Current Rating
30 A
Voltage Rating
250V AC
Phase
Single
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Shrouded
Yes
Grounding
Grounded
Housing Color
Yellow
Cap Type
No Cap
Standards
ANSI C73, CSA C22.2 No. 42 File LR-406, NEMA WD-6, NOM 057 Certified, RoHS Compliant, UL 498
Resistance Properties
Chemical Resistant, Impact Resistant, Weather Resistant
Weight
0.5 lb
Flange Material
Nylon
Wattage
7500W
Application
Female Connector Wiring Device
Number of Female Connectors
1
Description
This AC WORKS brand NEMA L6-30R wiring device is made of a very durable construction able to withstand impacts, chemicals, and weather. It has a weather-tight seal and strain relief structure with SJT, SJO, SOO, STW 12/3, 10/3, or 8/3 cable. This product features a locking connector, preventing items from becoming unplugged when in use.
