Shop AIGNEP USA

Exhaust Coupler, 3/8", Brass, 100 cfm

  • Mfr # 80622-06

  • Zoro # G5097176

product price:
$
25.75
/ea
Zoro's best price: not eligible for any other offers or promotions

Key Features

Interchange Type
Industrial
Material
Brass
Coupling Component
Socket
Hose Fitting Gender
Female
Connection Type
Threaded
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
80622-06
Zoro #
G5097176
UPC #
-
Country of Origin
Mexico

Dimensions

Hose Fitting Size
3/8 in
Coupling Size
1/4 in
Thread Size
3/8"-18
Overall Length
2 1/8 in
Body Size - Quick Connect Air Couplings
1/4 in
Max. Outside Dia.
1 3/16 in
Wire Rope Length
2 1/8 in
Length
2 1/8 in

Details

Item
Quick Connect Air Coupling
Interchange Type
Industrial
Material
Brass
Coupling Component
Socket
Hose Fitting Gender
Female
Connection Type
Threaded
Finish/Coating
Zinc Black Anodized
Max. Flow Rate
595 lpm
Coupling Locking Type
Safety Vent
Seal Material
Nitrile
Includes Valve
Yes
Color
Black, Silver
Temp. Range
0 Degrees to 180 Degrees F
Application
Pneumatic
Barbed
No
Valve Type
Poppet
Max. Working Pressure @ 70 F
220 psi
Connection Thread Type
NPT

Description

The AIGNEP USA - 80622-06 is a quick connect hose coupling designed for pneumatic applications. It supports connection and disconnection without tools using the integrated coupling mechanism. It is intended for use in pneumatic fluid transfer systems with connection/disconnection for air-line routing. It includes a vent-locking mechanism designed to vent and lock during connection/disconnection. It includes a poppet-type valve for controlling air flow during connection and disconnection. It is compatible with industrial interchange standards and is constructed primarily of brass with a zinc black anodized finish.

Key Features:

  • Application: Pneumatic
  • Material: Brass
  • Coupling Size: 1/4 in
  • Hose Fitting Size: 3/8 in
  • Hose Fitting Gender: Female
  • Connection Type: NPT (3/8"-18 thread size)
  • Coupling Component: Socket
  • Coupling Locking Type: Safety Vent
  • Valve: Includes a poppet-type valve
  • Max. Flow Rate: 595 lpm
  • Max. Working Pressure @ 70°F: 220 psi
  • Seal Material: Nitrile
  • Temperature Range: 0°F to 180°F
  • Finish/Coating: Zinc Black Anodized
  • Overall Length: 2.13 in
  • Max. Outside Diameter: 1.19 in
