Aignep Usa Push-Fit Tee Fitting, Push-to-Connect x Push-to-Connect x Universal, 12mm Tube OD, 3/8 in Pipe Size 55222-12-3/8 - main

Push-Fit Tee Fitting, Push-to-Connect x Push-to-Connect x Universal, 12mm Tube OD, 3/8 in Pipe Size

  • Mfr # 55222-12-3/8

  • Zoro # G5098068

product price:  $6.95
/ea

Key Features

Material
Plastic/Metal Combination
Max. Pressure
250 psi
Connection Type
Push-to-Connect x Push-to-Connect x Universal
Tube Size
12mm
Standards
EN 331, REACH, RoHS
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
55222-12-3/8
Zoro #
G5098068
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Tube Size
12mm
Pipe Size
3/8 in
Hex Head Size
51/64 in
Overall Length
2 1/8 in
Fitting Side C Pipe Size
3/8 in
Fitting Side A Tube Outer Diameter
12 mm
Fitting Side B Tube Outer Diameter
12 mm
Fitting Side 3 Tube Outer Diameter
3/8 in
Fitting Side 2 Tube Outer Diameter
12 mm
Fitting Side 1 Tube Outer Diameter
12 mm

Details

Item
Push-Fit Tee Fitting
Material
Plastic/Metal Combination
Max. Pressure
250 psi
Connection Type
Push-to-Connect x Push-to-Connect x Universal
Standards
EN 331, REACH, RoHS
Application
Air
Temp. Range
0 Degrees to 160 Degrees F
Fitting Shape
Tee
Fittings Sub-Category
Tees
Special Features
Universal Thread System Compatible with Inch and Metric Threads
Color
Black
Gasket Material
NBR70
Compliance
EN331, REACH, ROHS
Body Material
Composite
Maximum Operating Temperature
160 Degrees F
Fitting Side A Connection Type
Push-to-Connect
Fitting Material
Nylon
Compatible Tube Material
Copper, Nylon, Polyethylene, Polyurethane
Fitting Side C Connection Type
Universal
Minimum Operating Temperature
0 Degrees F
Includes Pre-Applied Thread Sealant
Pre-Applied Thread Sealant Not Included
System of Measurement
Imperial/Metric
Fitting Side B Connection Type
Push-to-Connect
Maximum Operating Pressure
250 psi
Connector Type
Adapter
Fitting Side 2 Connection Type
Push-to-Connect
Operating Temperature - Maximum
160 Degrees F
Operating Pressure - Maximum
290 psi
For Media Type
Compressed Air
Operating Temperature - Minimum
0 Degrees F
Fitting Side 3 Connection Type
Push-to-Connect
Fitting Side 1 Connection Type
Push-to-Connect

Description

Push-Fit Tee Fitting, Application Air, Color Black, Fitting Side A Connection Type Push-to-Connect, Fitting Side B Connection Type Push-to-Connect, Fitting Side C Connection Type Universal, Includes Pre-Applied Thread Sealant Pre-Applied Thread Sealant Not Included, Fitting Side C Pipe Size 3/8 in, Fitting Side A Tube Outer Diameter 12 mm, Fitting Side B Tube Outer Diameter 12 mm, Fitting Material Nylon, Maximum Operating Pressure 250 psi, Maximum Operating Temperature 160 Degrees F

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
